4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
Specifications
Model NO. :
BP93420-IB
Measuring Medium :
Liquid
Pressure range :
0kpa~10kpa...100MPa
Customized :
Customized
Transport Package :
Standard Export Packing with Carton
Protection Rating :
IP65
Price :
US $15-30 / Piece
MOQ :
1 Piece
Pressure Type :
Gauge Pressure, Absolute Pressure, Sealed Pressure
Trademark :
HTsensor
Housing Material :
316L
Production Capacity :
2000PCS/Month
Origin :
China
IP Rating :
IP65
Long-Term Stability :
+-0.2%F.S/Year(Typ.)
Certification :
CE, RoHS
Specification :
Silicon pressure sensor
HS Code :
9026209090
Accuracy Grade :
0.5G
Description

Product Description




BP93420IB Pressure Transmitter

Introduction:
BP93420IB pressure transmitter adopts the HT series diffusion silicon isolation oil-filled core as the signal measuring element. The signal processing circuit is located inside a stainless steel housing, converting the sensor signal into a standard output signal. The product has undergone rigorous testing and aging screening for components, semi-finished products, and finished products, ensuring stable and reliable performance.
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter



Product Features:
1. Wide measuring range, stainless steel structure, diverse pressure interface forms
2. Compact and lightweight design
3. Zero and full-scale adjustable
4. High precision, all stainless steel structure
5. Adjustable zero and full-scale

Applications:
1. Pressure measurement of non-corrosive gases and liquids with 316L stainless steel
2. Applied in the marine and aviation industries
3. Used in industrial on-site processes such as petroleum, chemical, metallurgy, power generation, and hydrology
4. Utilized in hydraulic and pneumatic control systems

Performance Parameters:
Measurement Range -100kPa…0kPa ~ 10kPa…100MPa
Pressure Type Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload ≤ 1.5 times of the rated range
Accuracy @ 25ºC ±0.25% (Typical) ±0.5% (Maximum)
Repeatability 0.1%FS
Hysteresis 0.1%FS
Long-Term Stability ±0.1%F.S/Year(Typical) ±0.2%F.S/Year(Maximum)
Zero Point Temperature Drift ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa)
Full Scale Temperature Drift ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa)
Compensation Temperature 0-70ºC(≤10mpa,customizable)
Operating Temperature -20ºC~80ºC
Storage Temperature -40ºC~120ºC
Vibration 10g,55Hz ~ 2kHz
Housing Material 304,316L
Diaphragm Material 316L
Insulation Resistance 100MΩ 100VDC
Explosion-proof Rating Ex db IIC T6 Gb
Protection Rating IP65
O-Ring Seal Fluoro rubber
Weight ~0.15kg

Output Signal Supply Voltage Output Type
4~20mA 12~30VDC 2/3/4 wire
0~10/20mA
3 wire
0/1~5V
0/1~10V
0.5~4.5V 5VDC

4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter



4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter


Ordering tips
1. When selecting the product, please ensure that the medium to be measured is compatible with the contact parts of the product.
2. When placing an order, please note that explosion-proof type products do not include digital display heads.
3. When ordering transmitters with an LCD or LED display head, the power supply for the transmitter should not be lower than 20VDC.
4. To ensure reliable operation of the product, it is recommended that users install lightning protection devices on-site and ensure that the product and power supply are  reliably grounded.
5. The rated working temperature range of the Fluoro rubber O-ring is -20ºC to 250ºC. When the product's operating temperature is below -20ºC, it is necessary to choose an EPDM O-ring seal.
6. The default cable length is 1.5m, available in three materials. If not specified, it will be supplied with polyethylene cable material. If you require a different cable material, please specify it in the order.
7. For special requirements such as strong vibration, instantaneous impact force, strong electromagnetic or radio frequency interference, please inform our company and specify them in the order.

4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
Order Guide
BP93420XX Pressure Transmitter
  Code Outline Construction
IB General Pressure Transmitter IX Display Pressure Transmitter
IE Shock-resistant Aviation Pressure Transmitter IIC/III Industrial General/ Display Pressure Transmitter
IF Moisture-proof Pressure Transmitter IIE/IIIE General/Display Pressure Transmitter
IN Air Conditioning Dedicated Pressure Transmitter
IC High-temperature Pressure Transmitter
IQ1/IQ2 Large Diaphragm /High-temperature Pressure Transmitter
  Measurement Range -0.1. . .0~0.01...100MPa
(0-X)Kpa or MPa X: Indicates the Actual Measuring Range
  Code Power Supply
D1 24VDC
D2 5VDC
D3 Other
  Code Output Signal
S1 4~20mADC S5 0~20mADC
S2 1~5VDC S6 0~10VDC
S3 0~5VDC S7 0.5~4.5VDC
S4 0~10mADC
  Code Pressure Connection
J1 M20×1.5
J2 G1/2
J3 G1/4
J4 7/16-20UNF
J5 Other
  Code Electrical Connection
B1 Hirschmann
B2 PG7 Plug
B3 Sealed Cable Output
B4 2088 Industrial Casing
B5 2088 Industrial Casing with Display
B6 Other
  Code Pressure Type
G Gauge Pressure
A Absolute Pressure
S Sealed Reference Pressure
 4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter
4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter4-20mA Stainless Steel Simple Pressure Sensor Pressure Transmitter

FAQ:
1. Q: What are the features of your pressure sensor transmitters?
A: High precision, durability, and excellent performance. Customization available.
2. Q: Can I customize special specifications?
A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service
3. Q: What is your production capacity?
A: Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling.
4. Q: What's the typical delivery period?
A: 5~8 working day for standard models. Customized products may vary.
5. Q: How are the products priced? Any discounts?
A: Competitive pricing with discounts for bulk orders or long-term partners.
6. Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 24 months after shipment, and our after-sales will respond with your questions in 24hrs, remote instruction by PC network is always available.
