Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Specifications
IP Rating :
IP65
Weight :
~0.25kg
Production Capacity :
2000PCS/Year
Origin :
Baoji, China
Accuracy Grade :
0.5G
Certification :
ISO
Pressure range :
0-500PA, -200kpa,
Measuring Medium :
Gas
Housing Material :
Aluminum
Specification :
Silicon pressure sensor
HS Code :
9026201090
Customized :
Customized
Trademark :
HT sensor
Protection Rating :
IP65
Transport Package :
Standard Export Packing with Carton
Price :
US $28-37 / Piece
Model NO. :
BP93420D-I
MOQ :
1 Piece
Warranty :
2 Years
Description

Industrial 4-20mA Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
BP93420DI Differential Pressure Transmitter



Introduction:
BP93420DI is a Micro-differential pressure transmitter that utilizes the piezoresistive effect of semiconductor silicon material to convert differential pressure into an electrical signal. It is mainly used for measuring small differential pressures of non-corrosive dry gases, suitable for applications in industries such as boiler air supply, underground ventilation in the power and mining industries, and pressure automatic detection in ultra-clean workshops for process control.
Product Features:
  1. Choice of aluminum or plastic casing design
  2. Lightweight and easy to install
  3. Undergone rigorous high and low-temperature testing to ensure wide temperature range usability
  4. High accuracy
Applications:
  1. Suitable for applications in boiler and mining industries
  2. Brewing and power industries
  3. Designed for detecting small differential pressures of non-corrosive gases
Performance Parameters
Measurement Range 0-500Pa, 0-1KPa,0-2KPa, 0-5KPa, 0-7kPa, 0-10KPa,0~~~200KPa
Pressure Type Differential Pressure
Static pressure 2 times of the rated range
Overload ≤ 1.5 times of the rated range
Accuracy @ 25ºC ±0.5% (Typical), ±1% (Maximum)
Zero Temperature Drift ±2.5%F.S/ºC(Typical) ±3%F.S/ºC(Maximum)
Span Temperature Drift ±2.5%F.S/ºC(Typical) ±3%F.S/ºC(Maximum)
Compensation Temperature 0-50ºC
Operating Temperature -20ºC~80ºC
Storage Temperature -40ºC~100ºC
Housing Material Aluminum alloy,Plastic
Relative humidity 0-80%
Pressure connection φ7 air nozzle or customizable
Protection Rating IP65
Cable material Polyethylene
Weight ~0.25kg
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter

Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter

Output Signal Supply Voltage Output Type
4~20mA 12~30VDC 2/3/4 wire
0~10/20mA
3 wire
0/1~5V
0/1~10V
0.5~4.5V 5VDC

Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Industrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure TransmitterIndustrial 4-20mA air Micro-Pressure Sensor Air Gas Wind Differential Pressure Transmitter
Ordering tips

1. When selecting the product, please ensure that the medium to be measured is compatible with the product parts in contact.
2. To ensure reliable operation, ensure that the measured medium is slowly and evenly pressurized on both the positive and negative pressure chambers of the transmitter.
3. During installation, it is recommended to position the pressure interfaces at both ends horizontally to minimize the impact on the product due to the installation position.
4. For special requirements such as strong vibration, instantaneous impact force, strong electromagnetic interference, and radio frequency interference, please inform the company and specify them in the order.
Order Guide
BP93420D Pressure Transmitter

Code Outline Construction
I Differential Pressure Transmitter

Measurement Range 0-500Pa, 0-1KPa,0-2KPa, 0-5KPa, 0-7kPa, 0-10KPa,0~~~200KPa

Code Power Supply
D1 24VDC
D2 5VDC
D3 Other

Code Output Signal
S1 4~20mADC S5 0~20mADC
S2 1~5VDC S6 0~10VDC
S3 0~5VDC S7 0.5~4.5VDC
S4 0~10mADC



Code Pressure Type
D Differential Pressure

Code Housing Material
01 Aluminum alloy
02 Plastic

Q&A
1. Q: What are the features of your pressure sensor transmitters?
A: High precision, durability, and excellent performance. Customization available.
2. Q: Can I customize special specifications?
A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service
3. Q: What is your production capacity?
A: Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling.
4. Q: What's the typical delivery period?
A: 5~8 working day for standard models. Customized products may vary.
5. Q: How are the products priced? Any discounts?
A: Competitive pricing with discounts for bulk orders or long-term partners.
6. Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 24 months after shipment, and our after-sales will respond with your questions in 24hrs, remote instruction by PC network is always available.
