350W Single Output Industrial Power Supply (ESP Series)

Overview

Place of Origin:Chengdu, China
Model Number:ESP
Output Type:Single
Weight:0.51kg/pcs
Type:Constant Voltage
Protection:Overload/Over voltage/Short circuit
Input Voltage:88VAC~132VAC,176VDC~264VDC
Input Frequency:47HZ~63HZ
Warranty:2 Years
Size:159mm×98mm×38mm
Working Temp.:-20℃~60℃

Specifications

Input voltage 88VAC~132VAC, 176VAC~264VAC

Input frequency 47HZ~63HZ

Inrush current <50A full load cold start

Hold up time ≥20ms @ 230VAC full load
Overload protection 120%~150%

constant current limiting, auto-recovery
Over voltage protection 115%~145%

Operating temperature -20℃~70℃(refer to output load derating curve)

Safety standard EN60950-1

EMC standard EN61000-6-2

EN61000- -4- -2,3,4,5,6,8,11

EN55022 Class B
Withstand voltage I/P-O/P: 1.5kVAC, 1min

I/P-FG: 1 5kVAC, 1min

O/P-FG: 0.5kVAC, 1min

Weight 0.92kg/pcs

OUR ADVANTAGES

OEM&ODM SERVICE
This company is engaged in the design,manufacture and sale of switching power series
LONG-TIME BURN-IN TEST
Each of the switch power is extremely safe and stable after 5 times testing
With high reliability,105℃long life capacitor,can withstand 300VAC,input voltage 5 seconds without damage.

FAQ

Q1: How many year warranty of your Led driver?
A: Two years
Q2: Do you have switch power factory?
A: Yes.We are OEM&ODM manufacturer in Chengdu
Q3: Do you offer sample of power?
A: Yes.We offer free sample ,but you need pay the shippment.
Q4: Is your power with copper transform or something?
A: We can do with complete copper transform and copper cladding aluminum.
Q5: Do you have any certification?
A: Yes.We have CE,ISO9001,ROHS,if you need other certification with large order,we can apply for it.
