USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
USB3.1 Type C to C Fiber Optical Cable
Specifications
Brand Name :
E-link
Model Number :
LNK-U31-AOC
Certification :
CE
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
100000PCS/Month
Delivery Time :
7-10 working days
Packaging Details :
Industrial PoE Switch Standard Carton Packaging
Cable Diameter :
4.3mm±0.15mm
Weight :
Depends on length
Max. Tensile Load :
221N
Protocol Specification :
USB 3.1, USB 3.0, USB 2.0 (copper)
Description

USB3.1 Type C to C Fiber Optical Cable


Product Advantages

► Plug and play, no need external power supply.

► Support USB 3.1 Gen 2 and full bandwidth reach up to 10Gbps.

► Supports both USB 2.0 and 3.1 in same cable up to 40 meters.

► Supports up to 100m (300ft.) cable length.

► Low EMI (electromagnetic interference) protection.

► Standard operating temp: 0 to 50C.

► Widely used on Industrial Camera, Machine Vision system, Medical System, Security Monitoring system, Conference system, Broadcasting system, High frequently used on Printer, Scanner, Touch Screen, Camera, Game Controller etc.

Technical Indexes

Performance

Protocol Specification

USB 3.1, USB 3.0, USB 2.0 (copper)

Transmission Data Rate

10Gbps

Interface

Input

USB Type-C

Output

USB Type-C

Power Supply

Low power consumption, no external power supply required

Cable

Cable Type

Optical fiber cable

Fiber Type

2-core MMF

Max. Cable Length

5m

Cable Jacket

TPE/85A

Color

Black

Min. Bending Radius

12mm

Working Environment

Operating Temperature

0℃ to +50℃

Storage Temperature

-40℃to +80℃

Optical Power

Input Voltage

5~20V

Power Supply Capability

3A

Power Consumption

≤ 500mW

Package

Package List

Anti-static bag, cable tie, transmission line, instruction manual

Attention:

During use, be careful to avoid excessive bending and breaking the fiber. For details, please refer to the bending radius.

Overview

E-link USB 3.1 fiber optical cable Under the help of optical fiber design, cable OD only 4.8mm, easy for installation, support plug & play, no need external power supply. And has lower EMI interrupt, and without signal loss at high-speed signal transmission. Different USB devices with comprehensive compatibility testing before shipment, has perfect compatible with most USB device.

Application

USB3.1 Type C to C Fiber Optical Cable


Ordering Information

Model

Description

LNK-U31-AOC-5

USB3.1 Type C to C Fiber Optical Cable, 5 Meters

LNK-U31-AOC-10

USB3.1 Type C to C Fiber Optical Cable, 10 Meters

LNK-U31-AOC-15

USB3.1 Type C to C Fiber Optical Cable, 15 Meters

LNK-U31-AOC-20

USB3.1 Type C to C Fiber Optical Cable, 20 Meters

LNK-U31-AOC-30

USB3.1 Type C to C Fiber Optical Cable, 30 Meters
