Specifications
Brand Name :
E-link
Model Number :
LNK-INJ501-90
Certification :
ROHS,FCC,CE
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,Paypal
Supply Ability :
1000 pcs/month
Delivery Time :
3-12 working days
Packaging Details :
Injector Standard Export Package
Keywords :
Industrial PoE Injector
Operating Temperature :
-40°C to 80°C (-40°F to 176°F)
MTBF :
>200,000hrs
Power Consumption: :
100W Max.
Dimensions (WxDxH) :
95 x 70 x 30 mm
Description

Industrial 5G 95W 802.3bt PoE++ Injector (12~48VDC)

Industrial 5G 95W 802.3bt PoE++ Injector (12~48VDC) Advantages

► 1 RJ45 Ethernet Data Input Port + 1 RJ45 Power over Ethernet Output Port (Data + Power)

► Support 95W LTPoE++ Power Sourcing Equipment

► Complies with IEEE 802.3at/bt PoE end-span/mid-span PSE

► Support 10/100/1000/2.5G/5G Base-TX

► Extensive LED indicators for PoE diagnostics

► 12~48V DC wide range power input with power booster function

► Up to 95-watt PoE budget (48VDC), 95-watt PoE budget (24VDC), 60-watt PoE budget (12VDC)

► Supports DIN-Rail and Wall-mount installation

► Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature

Industrial 5G 95W 802.3bt PoE++ Injector (12~48VDC) Overview

The LNK-INJ501-90 product is an Industrial hardened single-port PoE+ IEEE 802.3bt / LTPoE++ 95W 10/100/1000/2.5G/5G Base-TX PoE Injector with 12~48V DC Input and Voltage Booster. It allows you to connect the PoE device such as camera and access point with a non PoE LAN switch within the distance of 30m. Both the Ethernet port (to switch) and the PoE Out port (to PoE device) support 10/100/1000/2.5G/5G Base-T and are compliant with IEEE 802.3ab. It provides 95W PoE output.

Industrial 5G 95W 802.3bt PoE++ Injector (12~48VDC) Technical Indexes

Ethernet

Standards:

10/100/1000/2.5G/5G BASE-T Ethernet

Processing Type:

Forward

Half-duplex, Full-duplex

Forward Filter Rate:

7,440,000pps (5Gbps)

Cabling:

10/100/1000/2.5G/5G BASE-T: CAT7 or above

Maximum Distance:

CAT7 UTP up to 30m

Connector:

2x RJ45

Power over Ethernet:

Standard:

IEEE 802.3bt 4-pair Power over Ethernet

IEEE 802.3at Power over Ethernet Plus

IEEE 802.3af Power over Ethernet

Port:

RJ45

Power Pin Assignment

Data provide over pairs 1,2TX and 3,6RX

Power over spare pairs 1,2,4,5(+) and 3,6,7,8(-)

PoE Budget:

Up to 95-watt PoE budget (48VDC)

Up to 95-watt PoE budget (24VDC)

Up to 60-watt PoE budget (12VDC)



Industrial 5G 95W 802.3bt PoE++ Injector (12~48VDC) ordering information

Model

Description

LNK-INJ501-90

5G Hardened 1-port Ethernet Input + 1-port 95W PoE++ Output Injector with 12~48V DC wide range power input

Mounting Options

► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.

Power Options

► 120W/2.5A 48VDC Power Supply. Open Wire for Terminal Block

► Power Supply is to be purchased separately.
