2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
2U 14-Slot AC Output Rack mount Chassis
Specifications
Brand Name :
E-link
Model Number :
LNK-MC14
Certification :
CE, RoHS and FCC
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
100000PCS/Month
Delivery Time :
7-10 working days
Packaging Details :
Industrial PoE Switch Standard Carton Packaging
Power consumption :
<3W
Weight :
3.8KG
Dimensions (W x D x H) :
485 (W) x 210 (D) x 89 (H) (mm)
Case Color :
Black
Structure :
2U rack
Description

2U 14-Slot AC Output Rack mount Chassis

Product Advantages

► Suitable for standard 19 inch network rack

► 2U height, maximum 14 slots capacity

► All AC Output Sockets

► No DC Power Supply No FAN design

► Supports several module type media converters

► Supports hot-swappable operating

Overview

The 2U height 14-slot AC sockets rack mount chassis is specially designed for accommodating chassis-based Media Converters or other modules. It is a standard 19 inch 2U height rack mount chassis which can be mounted in the standard 19-inch rack. The chassis lets you install multiple media converters in an equipment rack together with the network devices. This provides for space saving, and the cabling will look neat. The chassis works with all 14-slot AC 110V/220V typical output sockets, so it needs neither AC/DC power supply nor cooling fan. The no AC/DC power supply and no cooling fan design will greatly increase the reliability of system.

Technical Indexes

Parameter

Specifications

Number of slots

14

Structure

2U rack

Power input

AC Voltage: AC 100~240V;

frequency: 50/60 Hz

Fuse: 250V T5A

Power output

Output Voltage: AC 100-240V 50/60Hz (same as Input)

Total Power Consumption: Less than 300Watts

Case Material

Iron

Case Color

Black

Net Weight

3.8KG

Dimensions

485 (W) x 210 (D) x 89 (H) (mm)

Connectors

AC Input: IEC-320 C4

AC Output: IEC-320 C6

Max power consumption

95W

Operating temperature

0~45ºC

Cooling

Free air convection

Operating humidity

5%~90%

Maintaining temperature

-40~70ºC

Maintaining humidity

5% ~ 90% non-condensing


Ordering Information

Model

Description

LNK-MC14

2U Height 14-Slot AC Output Rack mount Chassis
