7th Kaby Lake-U I7-7500U OPS PC Motherboard With NGFF RS-232 For Teaching Interactive Whiteboard
7th Kaby Lake-U I7-7500U OPS PC Motherboard With NGFF RS-232 For Teaching Interactive Whiteboard
7th Kaby Lake-U I7-7500U OPS PC Motherboard With NGFF RS-232 For Teaching Interactive Whiteboard
7th Kaby Lake-U I7-7500U OPS PC Motherboard With NGFF RS-232 For Teaching Interactive Whiteboard
Specifications
Brand Name :
VEGASHINE / OEM
Model Number :
OPS-PM07
Place of Origin :
Shenzhen China
MOQ :
1 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 units per Month
Delivery Time :
3 to 10 work days
Packaging Details :
Carton
Processor :
Kaby lake-U i3-7100U / i5-7200U / i7-7500U / Celeron® 3865U
Memory :
1*DDR4 SODIMM 260 Socket
Network :
1*Gigabit LAN
Display :
VGA / HDMI
Serial port :
1* RS232
NGFF_SSD :
1*NGFF_SSD Port
Power :
Single input DC power supply, DC12-19V
Size :
165*114.2 mm
Description

Notice:

When you inquiry , you can choose the following Model

OPS-PM07-3865U, Integrated Kaby Lake-U Intel® Celeron® Processor 3865U dual cores 2 threads 1.8GHz Processor

OPS-PM07-3965U, Integrated Kaby Lake-U Intel® Celeron® Processor 3865U dual cores 2 threads 2.2GHz Processor

OPS-PM07-I3 , Integrated Kaby Lake-U i3-7100U dual cores 4 threads 2.4GHz Processor

OPS-PM07-I5 , Integrated Kaby Lake-U i5-7200U dual cores 4 threads 2.5~3.1GHz Processor

OPS-PM07-I7 , Integrated Kaby Lake-U i7-7500U dual cores 4 threads 2.7~3.5GHz Processor

DC12-19V Kaby lake-U i3-7100U / i5-7200U / i7-7500U / Celeron® 3865U OPS PC mainboard with1*RS-232 NGFF_SSD for Electronic Whiteboard

Key features

Integrated Kaby Lake i7-7500U dual cores 4 threads 2.7~3.5Ghz

Support 1 *DDR4 SODIMM 260 Socket

Intel HD Graphics 620

Onboard 1*Gigabit Ethernet Port

1*SATA3.0

1*NGFF_SSD Port

1*Gigabit LAN

1*HDMI

1*VGA

2*USB3.0

4*USB2.0

Size: 165*114.2 mm

Specifications

Processor CPU

Integrated Kaby lake-U i3-7100U / i5-7200U / i7-7500U / Celeron® 3865U
CPU package BGA
chipset Intel Kaby lake-U serial CPU
BIOS EFI BIOS
Memory Technology Architecture Single channel DDR4 2133MHz
socket 1 *DDR4 SODIMM 260 Socket
Video Graphic controller Intel HD Graphics 620(I3-7100U graphics card); graphics models related to CPU
VGA VGA support max resolution:2048x1536
HDMI support max resolution(HDMI1.4)4096*2304@30HZ support 4k display output
Dual display HDMI+VGA sync or asynchronous display
I/O back panel Port 1*VGA,1*HDMI,1*LAN,2*USB3.0/,4*USB2.0,1*MIC-OUT/LINE-OUT, 1 * Power indicator, 1 * Hard disk indicator 1 * , 1 * restart button
Internet controller 1 * RTL8111E-V Gigabit Ethernet, RJ45 interface
Audio controller Realtek HD ALC662 audio decoding (left and right channel + microphone)
Super I/O controller IT8163E
Hardware control Watchdog timer 0-255 seconds to provide watchdog routines
Cooler Aluminum fan heatsink
Input / output interface USB

2*USB3.0 compatible with USB2.0 / 1.1,max support +5V/1A

4*USB2.0
COM 1*RS-232
Expansion bus NGFF 1*NGFF Port(KEY E)
NGFF 1*NGFF port , support 3G/4G Module
storage SATA 1 standard SATAIII interface, maximum transfer rate of 6Gb/s (and SATA_HDD one by one, default is SATA_HDD)
SATA_HDD 1*SATA_HDD hard disk interface, maximum transfer rate of 6Gb/s (and SATA two)
NGFF 1*NGFF_SSD Port
Power type Power type Single input DC power supply,DC12-19V,+/-5%
Power consumption 35W
Working temperature Working temperature -20℃ ~ +60℃
Storage temperature -40℃ ~ +85℃
Operating humidity 0% to 90% relative humidity, no condensation
Storage humidity 0% to 90% relative humidity, no condensation
size size 165*114.2 mm
weight 0.5KG

About RMA

1--Warranty 1 year

2--If buyer confirm the item can`t work well due to the non-artificial factors,buyer can return it to our company. Buyers should keep it with proper packaging.

3--Buyers are responsible for return to china freight cost .

4--Seller will repair item and ship the repaired one to buyer,seller will pay the shipping cost from China to Buyer address.

5--Please contact us firstly before returning defective goods by email.

Application

Teaching whiteboard / Education electronic whiteboard / Classroom interactive whiteboard

Meeting interactive whiteboard / Coference interactive whiteboard

Shipping

Support DHL / UPS / FEDEX / air shipping deliver time 4 to 9 business days

Support Sea shipping for Batch order deliver time 25 to 50 days
