Specifications
Brand Name :
QIJIE
Model Number :
SW-004
Certification :
CE,SGS,ISO
Place of Origin :
Hebei, China
MOQ :
100kg
Payment Terms :
30%TT in advance, Balance before loading
Supply Ability :
30000 kg/month
Delivery Time :
10-15 working days
Packaging Details :
wooden case
Material :
Stainless Steel Wire
wire diameter :
0.17mm
Description

Chinese Stainless Steel Wire Rods 1020 1050 1060 316L 304L Coils Welding Processing Service From Trusted​

Nichrome alloy wire includes pure nickel, NiCr alloy, Fe-Cr-Al alloy and copper nickel alloy.
Nickel chrome alloys: Ni80Cr20, Ni70Cr30, Ni60Cr15, Ni35Cr20, Ni90Cr10,Ni30Cr20, pure nickel Ni200 and Ni201
FeCrAl alloy: 0Cr25Al5, 0Cr23Al5, 0Cr21Al4, 0Cr27Al7Mo2, 0Cr21Al6Nb, 0Cr21Al6.
Copper nickel alloy: CuNi1, CuNi2, CuNi6, CuNi8, CuNi10, CuNi23, CuNi30, CuNi44, Constantan,CuMn12Ni
Our Nichrome alloy are in the form of wire, coil, ribbon, strip, foil
Nichrome wire sizes are:
Wire: 0.018mm-10mm
Ribbon: 0.05*0.2mm-2.0*6.0mm
Strip: 0.5*5.0mm-5.0*250mm
Bar: 10-100mm
Nichrome Grade: Nichrome 8020,Ni70Cr30,Ni80Cr20, Ni60Cr15, Ni35Cr20, Ni30Cr20
NiCr 80/20 also called Chromel A, Cr20Ni80, N8, Nichrome V, HAI - NiCr 80, Tophet A, Resistohm 80, Cronix 80, Protoloy, Alloy A,
MWS-650, Stablohm 650, NCHW1
nicr8020 characteristic
Chemical Content %: 80.00 Nickel, 20.00 Chrome
Max continuous service temperature: 1200ºC
Resisivity: 1.09 mm2Ω /m
Density: 8.4g/cm3
Thermal conductivity: 60.3kj/mhc
Coefficient of thermal expansion: 18*10-6/c
Melting point: 1400ºC
Elongation: Min 20%
Alloy Nomenclature Performance
Ni80Cr20
Ni70Cr30
Ni60Cr15
Ni35Cr20
Ni30Cr20
Main Chemical composition
Ni
Rest
Rest
55.0-61.0
34.0-37.0
30.0-34.0
Cr
20.0-23.0
28.0-31.0
15.0-18.0
18.0-21.0
18.0-21.0
Fe
≤1.0
≤1.0
Rest
Rest
Rest
Max. continuous service temp. of element(ºC)
1200
1250
1150
1100
1100
Resistivity at 20ºC (μΩ·m)
1.09
1.18
1.12
1.0
1.04
Density(g/cm3)
8.40
8.10
8.20
7.90
7.90
Thermal conductivity (KJ/m·h·ºC)
60.3
45.2
45.2
43.8
43.8
Coefficient of lines expansion(α×10-6/ºC)
18.0
17.0
17.0
19.0
19.0
Melting point approx.( ºC)
1400
1380
1390
1390
1390
Elongation at rupture(%)
>20
>20
>20
>20
>20
Micrographic structure
austenite
austenite
austenite
austenite
austenite
Magnetic properties
nonmagnetic
nonmagnetic
Weak magnetic
Weak magnetic
Weak magnetic
The application areas of nickel-chromium alloy strips include: Petrochemical industry: used to manufacture pipes, valves, pumps and other components in petrochemical equipment, as well as catalyst carriers for petrochemicals. Aerospace industry: used to manufacture high-temperature components such as engines, turbine blades, and combustion chambers. Chemical industry: used to manufacture reaction kettles, heat exchangers and other components in chemical equipment. Devices: used to manufacture devices such as artificial joints and dental implants. Other fields: such as nuclear industry, electronics industry, etc.

Detailed Photos

NiCr 80:20 - Industrial furnaces (upto 1200°C), electric cooking equipment, precision resistors.
NiCr 70:30 - Industrial furnaces (upto 1230°C) with alternating oxidizing/reducing atmosphere, precision resistors.
NiCr 60:15 - Industrial furnaces (upto 1100°C), electrically heated equipment, high-resistance and potentiometer resistors.
NiCr 40:20 - Domestic heating appliances (upto 1050°C), furnaces in carburising or semi-reducing atmosphere.
NiCr 30:20/ NiCr 20:25 - Industrial furnaces (upto 1050°C), heating elements of cooking equipment.
