Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard
Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard
Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard
Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard
Specifications
Brand Name :
QIJIE
Model Number :
Steel Wire Rope Mesh
Certification :
CE,SGS,ISO
Place of Origin :
Hebei, China
MOQ :
10 square meters
Payment Terms :
30%TT in advance, Balance before loading
Supply Ability :
3000 m2/month
Delivery Time :
10-15 working days
Packaging Details :
wooden case
Material :
STAINLESS STEEL WIRE
Type :
Rope Mesh, Ferrule Type or Knotted Type
Application :
Protecting Mesh
Weave Style :
Plain Weave
Technique :
woven
Processing Service :
Weave
Raw Material :
Stainless Steel 304 316, Galvanized Wire
Accessories :
All could be provided
Email :
devin@industrialmetalmesh.com
whatsapp :
+8615369013183
Description

Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard​

Stainless Steel Wire Rope Mesh Netting, Cable Mesh Net
Also called SS cable mesh) made of high quality stainless steel wire twisted together, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in the harsh environments. And its largest benefit is particular resilience and flexibility.

High-Strength Stainless Steel Construction: Manufactured from premium AISI 304, 316, or 316L stainless steel cables, this stainless steel rope mesh delivers outstanding tensile strength, corrosion resistance, and long-term durability. The flexible cable structure ensures reliable performance in harsh outdoor environments such as coastal areas, high humidity zones, and industrial spaces.
Flexible Yet Secure Structure: The cable rope mesh system features an interwoven diamond pattern that provides excellent flexibility while maintaining high load-bearing capacity. This unique design absorbs impact effectively, making it ideal for safety barriers, animal enclosures, and architectural protection systems. The mesh can be stretched or framed to fit various installation requirements.
Customizable Specifications for Projects: Available in a wide range of rope diameters, mesh apertures, and panel sizes, the stainless steel cable mesh can be tailored to meet specific engineering and architectural needs. It supports multiple installation methods including ferrule type and knotted type, allowing seamless integration into different project designs.
Excellent Transparency and Aesthetic Appeal: With its lightweight and open structure, architectural stainless steel mesh offers high visibility and a modern appearance while maintaining safety. It blends naturally with surrounding landscapes and buildings, making it a preferred choice for zoo enclosures, green walls, balustrade infill, protective fencing, and decorative architectural facades.
Low Maintenance and Long Service Life: The corrosion-resistant stainless steel material requires minimal maintenance and maintains its strength and appearance for years. Compared with traditional fencing materials, stainless steel rope mesh reduces replacement costs and provides a reliable, cost-effective safety solution for long-term infrastructure and architectural projects.

Stainless Steel Wire Rope Mesh Netting, Cable Mesh Net

Also called SS cable mesh) made of high quality stainless steel wire twisted together, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in the harsh environments. And its largest benefit is particular resilience and flexibility.
Material
stainless steel 304, 304L, 316, 316L
Surface treatment
primary color or black oxide finish
Cable diameter
1.0-5.0 mm
Mesh opening sizes
25-200 mm
Mesh opening angles
20°, 30°, 60°, 70°, 75°. Mesh aperture at 60° as standard opening.
Construction of wire cable
7 × 7, 7 × 19
Connection
ferruled or knotted
Ordering
specific to order, according to the project.
Application
zoo mesh, green facades, aviary mesh, decorative mesh, fall protection netting, bridge cable mesh, stairwell guidance, etc.

Specification
Structure
Diameter(mm)
Aperture(mm)
7*7
1.0
10*10
7*7
1.2
15*15
7*7
1.2
20*20
7*7
1.5
25*25
7*7/7*19
2.0
30*30, 50*50
7*7/7*19
2.5
50*50, 80*80
7*7/7*19
3.0
50*50, 80*80,100*100
7*7/7*19
3.5
80*80,100*100, 150*150
7*7/7*19
4.0
100*100, 150*150, 200*200
Length: 1-100m
Width:1-10m

Heavy Duty Stainless Steel Wire Rope Mesh Custom Thickness Cable Net for Playground Safety Children Protection Guard

Applications:
1. Steel Mesh Balustrade - bridge, stair, balcony, path
2. Cable Mesh - Excellent Solution to Safety
3. Safety Net - Structural Measure to Prevent Suicide
4. Helipad Safety Net - Modular Heliport Webbing
5. Cable Zoo Mesh - Solution to Enclosing Most Animals
6. Aviary Netting - Lightweight, Durable and Long Lasting
7. Green Facade - Cable System for Most Climbing Plants

Advantages

High-Strength Construction: Durable 304/316 Stainless Steel ensures longevity and reliability.
Exceptional Stability: Multiple junction points and high-strength closed ferrules provide robust support.
Superior Corrosion Resistance: Perfect for heavy-duty plant support in various environments.
Professional Factory: Over 16 years of experience guarantees high-quality and efficient production.
Customizable Packaging: Special packages can be tailored to meet specific customer needs.
