Stainless Steel Modular Interlocking Steel Grating for Data Centers
Stainless Steel Modular Interlocking Steel Grating for Data Centers
Stainless Steel Modular Interlocking Steel Grating for Data Centers
Stainless Steel Modular Interlocking Steel Grating for Data Centers
Specifications
Brand Name :
Dimpled Hole Metal Sheets
Model Number :
Dimpled Hole Metal Sheets
Place of Origin :
China
MOQ :
10pieces
Payment Terms :
30%TT in advance, Balance before loading
Supply Ability :
1000pieces
Delivery Time :
15-18days
Packaging Details :
pallets
Chemical Composition :
Fe, C, Si, Mn, S, P
Alloy Or Not :
Non-Alloy
Project Solution Capability :
graphic design, 3D model design, total solution for projects
Application :
Villa
Surface Treatment :
Hot-DIP Galvanizing, Painting or Untreated
Grate length :
1000mm
Grate width :
800mm
Bearing bar width x thickness :
25x3mm
Bearing bar shape :
Plain, Serrated I bar type Style Steel Grating
Cross bar shape :
round,twisted,bar shape
Mesh size :
30x100mm
Email :
devin@industrialmetalmesh.com
whatsapp :
+8615369013183
Description

Stainless Steel Modular Interlocking Steel Grating for Data Centers​

Steel grating (also known as steel grating plate or grid plate) mainly includes fiberglass reinforced plastic grating, carbon steel grating, galvanized steel grating, stainless steel grating, serrated steel grating, interlocking steel grating, composite steel grating, special-shaped steel grating, manhole covers, steel ladder treads, platform steel grating, etc.
Product Features
Durability: Constructed from high-quality carbon or stainless steel, ensuring long-lasting performance in demanding environments.
Load-Bearing Capacity: Engineered to support heavy loads, making it ideal for industrial applications such as factories and warehouses.
Slip-Resistant Surface: Features a textured surface that enhances safety by reducing the risk of slips and falls.
Customizable Sizes: Available in various sizes and spacing options to meet specific project requirements and applications.
Optimal Drainage: Open design allows for effective water drainage and air circulation, reducing the risk of pooling and enhancing hygiene.

Production name
Steel grating
Material
Carbon steel, Stainless steel, Aluminum
Surface treatment
Hot dipped galvanized, Spray-painting, Polished and powder coated
Bearing Bar type
Flat bar, Serrated bar, I-bar, inserting steel grating etc
Beaing bar size
20*3mm, 25*3mm, 30*3mm, 32*3mm, 40*3mm, 50*3mm, 60*3mm, 70*3mm
20*4mm, 25*4mm, 30*4mm, 32*4mm, 40*4mm, 50*4mm, 60*4mm, 70*4mm
20*5mm, 25*5mm, 30*5mm, 32*5mm, 40*5mm, 50*5mm, 60*5mm, 70*5mm
Mesh size
30*100mm, 40*100mm, 50*100mm,
30*50mm, 40*50mm, 50*50mm,
30*30mm, 34*38mm
Use to
flooring, catwalk, decking, stair tread, fencing, ramp, dock, trench cover, drainage pit cover, maintenance platform, workshops, motor rooms, trolley channels, heavy loading areas, boiler equipment and heavy equipment areas, etc.

metal walking grates introduction-- galvanized road drainage grates

Bearing bar type Flat bar I bar Serrated bar
Cross bar type Twisted bar Round bar flat bar
Production process welded Pressure locked
Surface treatment Self-colour Galvanized painted
application Platform walkway&floor Trench cover Steel stair treads
Suspended ceiling Barrier fence

bearing bar types:

surface treatment: mill finish,hot dip galvanized,painted

steel grating standard-- galvanized road drainage grates

Steel Grating Standard
Steel Grating Standard Steel Standard Galvanizing Standard
China Standard YB/T 4001.1-2007 GB700-88 GB/T13912-2002
USA Standard ANSI/NAAMM (MBG531) ASTM (A36) ASTM (A123)
U.K. Standard BS4592 BS4360 (43A) BS729
Australia Standard AS1657 AS3679 AS1650
Deutsche Standard DIN24537 DIN17100-80 DIN50976

Advantages:
high strength, anti-slip, ventilation and light transmission properties.

Steel grating is widely used in the following fields:
1. Petrochemical, power and metallurgy, sewage treatment and other industrial fields.
2. Drainage systems, stairs and railings, commercial decoration and other municipal and architectural fields.
3. Bridges and tunnels, ports and ships and other transportation and marine engineering.
4. Garbage treatment plants, agricultural facilities and other environmental protection and agricultural fields.
