Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
Specifications
Model Number :
QJ-004
Material :
Stainless Steel Wire,316,304
Packaging Details :
as requirement
Payment Terms :
TT/LC
Email :
devin@industrialmetalmesh.com
Place of Origin :
China
Product name :
Square 4X4 Woven Flour 100 Micron Stainless Steel Wire Mesh
MOQ :
50 rolls
Delivery Time :
15 - 20 days
Wire diameter :
Requirement
Price :
discuss
Width :
Usually 1M
Certification :
ISO9001
Weave style :
Plain/Twill Weave
Supply Ability :
1000 rolls per week
whatsapp :
+8615369013183
Brand Name :
QIJIE
Technique :
Woven
Description

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications

Name
Stainless steel woven wire mesh
Raw materials:
stainless steel
Feature
Core advantage: Stainless steel (such as 304, 316, etc.) contains alloying elements such as chromium and nickel, forming a dense oxide film (passivation layer) on the surface, which can resist corrosion from media such as water, acid, alkali, and salt.
High temperature stability: It can withstand high temperatures of 300-800 ℃ for a long time (depending on the material, such as 304 can withstand 500 ℃, 316 can withstand 800 ℃), and has excellent oxidation resistance.
High strength and wear resistance
Application
1. For acid, alkali screening and filtration under industrial conditions
2. For the oil industry to do mud net, chemical fiber chemical industry, so sieve filter, electroplating
3. For mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries
4. keeping different species of inserts out, filtering some small items, mending windows and doors, etc
  • Plain /Twill Square Woven Mesh
    Mesh count Wire Dia Width of Opening Open area
    Inches mm Inches mm %
    1X1 0.157 4 0.84 21.4 71
    4X4 0.063 1.6 0.187 4.75 56
    8X8 0.043 1.1 0.08 2.08 42
    10X10 0.039 1 0.06 1.54 36
    12X12 0.023 0.584 0.06 1.52 51.8
    14X14 0.023 0.584 0.048 1.22 45.2
    16X16 0.018 0.457 0.0445 1.13 50.7
    18X18 0.017 0.432 0.0386 0.98 48.3
    20X20 0.016 0.406 0.034 0.86 46.2
    24X24 0.014 0.356 0.0277 0.7 44.2
    30X30 0.012 0.305 0.0213 0.54 40.8
    35X35 0.011 0.279 0.0176 0.45 37.9
    40X40 0.01 0.254 0.015 0.38 36
    50X50 0.008 0.203 0.012 0.31 36


    Material: SUS302, 201, 304, 304L, 316, 316L, 310, 310S, etc.

    Use:
    1. Used for screening and filtration under acid and alkali environmental conditions. In the petroleum industry, it is used as a mud net, in the chemical and chemical fiber industry, as a screen filter, and in electroplating...
    2 Used in mining, petroleum, chemical industry, food, medicine, machinery manufacturing and other industries...

    Features:
    1. Uniform mesh, good production reproducibility;
    2. Good resistance to acid, alkali and corrosion;
    3. High strength,tensile strength, toughness and wear resistance, long service life;
    4. Uniform structure, non - crimp, easy to use, uniform thickness, antistatic;
    5. High temperature oxidation resistance, 304 stainless steel screen nominal tolerance temperature of 800 degrees Celsius, 310S stainless steel screen name it can withstand temperatures up to 1150 degrees Celsius

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
316L stainless steel wire mesh application
  • For various filtration and separation requirements in the chemical industry, petroleum, Mining, shipbuilding, mining, food, .
  • Heat exchangers.
  • Decoration mesh.
  • Insect screen/mosquito screen.
  • Aerospace.
  • Waster water and ballast water filter.
  • Seawater treatment equipment.
  • Wire Mesh Basket Manufacturing.
  • Screen printing.

Other things you need to know about 316 stainless steel mesh

1. How to order?

When ordering the 316L stainless steel wire cloth, please specify the mesh count, wire diameter, hole size, weave type, mesh width, and length.

For example:
SS316L Screen Mesh 120 x 3′ x 100′ x 0.08mm Inquiry
SS316L Screen Mesh 100 x 3′ x 100′ x 0.1mm Inquiry.

More specifically such as:
Stainless steel mesh 316L, DTW 200/600, 40inch, 30meter , 1 roll
SUS 316L mesh, DTW 10 micron 200 x 1400 mesh, 0.07/ 0.04mm, size: 1m x 30m, 1 roll

2. Deep processing services

The wire mesh ss316 can be cut into different shapes of sheets, It can also be processed into filter tubes and filter caps.
For example, SS316L Screen Mesh 20 x 4 feet x 6 feet Long sheet, or SS316L Screen Mesh 60 x 59mm diameter Circular.
It can also be slit, for example, 200 mesh ss316 wire mesh can slit into 500mm width, and there will be 2 cutting rolls from 1m width 200 mesh 316 stainless steel mesh.

3. Detail application example

325 mesh 0.035mm wire diameter twill weave 316L stainless steel mesh used for stainless steel filter cartridge production.
300 mesh, 350 mesh, 400 mesh, 500 mesh Plain weave 316L stainless steel wire mesh used as screen printing mesh in Glass, ceramics, metals, plastics, rubber, and printed circuits industries.
24/110 mesh Dutch weave 316L stainless steel mesh used in the production of sunflower oil.

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications

Premium Twill Woven Stainless Steel Wire Mesh for Versatile Applications
