Specifications
Brand Name :
XMESH
Model Number :
QJ-218
Certification :
SGS
Place of Origin :
Hebei, China
MOQ :
200pcs
Payment Terms :
30%TT in advance, Balance before loading
Supply Ability :
10000 pcs one month
Delivery Time :
15-25days
Packaging Details :
loose packed or with steel pallets
Material :
Galvanized steel wire
Wire diameter :
4.0 / 5.0 mm
Mesh :
50 x 100 mm, 75 x 75 mm
Type :
Welded mesh
Hole Shape :
Square, rectangular
Dimension :
1 x 1 x 1 m, 2 x 1 x 1 m
Description

Galvanized Pvc Hot Dipped Welded Gabion Basket 4.0 / 5.0 Mm Dia

Welded Gabion is high quality steel mesh. They can be filled on site with hard durable stone materials to form mass gravity retaining structures. Owing to their inflexibility, welded gabions can not adapt to differential settlement or be used in water courses. In comparison with woven wire gabions, welded gabions offer a higher strength. In order to meet different project requirements, various wire diameters and unit sizes are available for welded gabion boxes.

Nominal Box sizes

(m)

Mesh size

(mm)

No. of diaphragms

(no.)

Capacity per box

(m3)
1.0x1.0x0.5

50x50

75x75

50x100

100x100

 0 0.50
1.0x1.0x1.0 0 1.00
1.5x1.0x0.5 0 0.75
1.5x1.0x1.0 0 1.50
2.0x1.0x0.5 1 1.00
2.0x1.0x1.0 1 2.00
3.0x1.0x0.5 2 1.50
3.0x1.0x1.0 2 3.00
4.0x1.0x0.5 3 2.00
4.0x1.0x1.0 3 4.00

Application

  • prevent soil loss,prevent flood and landslide
  • yard decoration stone wall fence
  • military defense wall for defence works
  • basement for road
  • plant landscope
  • decoration crafts for home yard etc
  • rock filled retaining wall fence
