2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports
Specifications
Brand Name :
Olycom
Model Number :
OM4X2400(2)GE
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Guangdong, China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T,PayPal
Supply Ability :
3000pcs/month
Delivery Time :
4~8 working days
Packaging Details :
Netural Packing
Product name :
24 port 2.5G Ethernet Switch
Power :
AC 100-240V, 12V 4A
Transfer Method :
Storage and forward
LEDs :
Power, network, fiber
Bandwidth :
160Gbps
Product Size :
440*205*44mm
Description


2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop

24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports

Key Features of 24 port 2.5G Ethernet Switch


  • 24* 100/1000/2500M RJ45 ports+2* 10G SFP+ ports;
  • Comply with IEEE 802.3, IEEE802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.3x;
  • Ethernet ports support 10/100/1000M/2.5G self-adaptive;
  • Support port Auto MDI/MDIX;
  • Panel indicator lights monitor working status and help failure analysis;
  • Flow control mode, full duplex adopts IEEE802.3x standard, half duplex adopts Back pressure standard;
  • Support Port Surge Protection: Common Mode 6KV, Differential Mode 2KV (Class C); ESD air 8KV, Contact 6KV (Class C)


Specification of 10G Fiber Ethernet Switch

I/O Interface

Power

AC 100-240V

Ethernet

24* 100/1000/2500 Mbps RJ45 Ports

2* 10G SFP+ Ports

Performance

Bandwidth

160Gbps

Packet Forwarding Rate

119.04Mpps

MAC Address Table

16K

Transfer Method

Storage and forward

Standard

Network Protocol

IEEE802.3 (Ethernet)

IEEE802.3u (Fast Ethernet)

IEEE802.3ab(Gigabit Ethernet)

IEEE 802.3bz (5G Ethernet)

IEEE 802.3z (Gigabit Ethernet)

IEEE 802.3ae (10G Ethernet)

IEEE802.3x (Flow control)

Industry Standard

EMS: EN61000-4-2 (ESD)

EN61000-4-5(Surge)

Network Medium

10Base-T: Cat3, 4, 5 or above UTP/STP(≤100m)

100Base-TX: Cat5 or above UTP/STP(≤100m)

1000Base-TX: Cat5 or above UTP/STP(≤100m)

2.5GBase-T: Cat5e or above UTP/STP(≤100m)

5GBase-T: Cat6 or above UTP/STP(≤100m)

10GBase-T: Cat6a or above UTP/STP(≤100m)

Network Medium

1000BASE-SX: 62.5μm MMF(multi mode) (Minimum range:2m～275m) or 50μm MMF

1000BASE-LX: 62.5μm/50μm MMF(Minimum range:2m～550m) or 10μm SMF(Minimum range:2m～5km)

2500BASE-X: G.652D SMF(Single mode) (Minimum range:2m～500m or 2m～5Km)

10GBASE-SR: OM1/OM2/OM3 or above MMF(Operating range:2m～300m)

10GBASE-LR: IEC B1.1 and B1.3 SMF(Minimum range:2m～10km)

Certificate

Safety Certificate

CE, FCC, RoHS

Environment standard

Working Environment

Working Temperature: 0~40°C

Storage Temperature: -40~70°C

Working Humidity: 10%~90%, non-condensing

Storage Temperature: 5%~95%, non-condensing

Indicator

PWR

On: Powered on

Off: Powered off

1-24 ports

Green on: 2.5G Link connect normal

Yellow on: 10/100/1000M Link connect normal

Off: Link off

Flashing: Data transmitting

25-26 Ports Green LIght

On: 10G Link connect normal

Off: Link off

Flashing: Data transmitting

SM

The default speed of the optical port is 10G/2.5G, which changes to 10G/1G after pressing the switch button

Dialing

On: VLAN mode is enabled (ports 1 to 22 are isolated and can only communicate with the uplink port)

Off: VLAN mode is off (all ports can communicate with each other)

Physical Specification

Structure Size

Product Size: 440*205*44mm

Package Size: 500*290*85mm

Product Net-Weight: 2.61KG

Product Gross-Weight: 3.12KG

Packing Info

Carton size: 520*445*310mm

Packing Qty: 5 pcs

Packing weight: 16.6KG

Power Voltage

AC 100-240V 12V 4A

Power

Maximum 36W

Packing List

1 switch, 1 adapter, 1 manual, 1 certificate


Dimension

2.5G Ethernet Switch 24 port 10G Fiber Ethernet Switch Desktop 24*10/100/1000/2500M RJ45 ports+2*10G SFP+ ports


Packing List


  • 1pc 24 port 2.5G Ethernt Switch
  • 1 pc power adapter
  • 1pc user manual
  • 1pc certification


Application


  • Metro Optical Broadband Network: Data network operators such as telecommunication, cable TV, and network system integration, etc.
  • Broadband private network: Suitable for financial, government, oil, railway, electric power, public security, transportation, education and other industries.
  • Multimedia transmission: Integrated transmission of images, voice and data, suitable for remote teaching, conference TV, videophone and other applications.
  • Real-time monitoring: Simultaneous transmission of real-time control signals, images and data.
