120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M
Specifications
Brand Name :
Olycom
Model Number :
OM011008-PSE-GE
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Guangdong, China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
T/T, PayPal
Supply Ability :
5000pcs/month
Delivery Time :
3~5 working days
Packaging Details :
1pc in a box
Product name :
8 port gigabit POE Switch
Power Adapter Voltage :
AC 110V-240V
PoE Ports :
8 ports support poe
Brand :
Olycom/customized/no brand
PoE Power Supply :
12 45 + ,36 78- , 8 core power supply
Switching Capacity :
2.0Gbps
Description

120W Unmanaged POE Switch 8 PoE

10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M

Introduction of unmanaged switch

  • Adopts the latest high-speed Ethernet switching chip and ultra-high backplane bandwidth design
  • With extremely fast data processing capability to improve smooth data transmission performance.
  • 8 Poe-powered RJ45 ports and 2 RJ45 uplink ports, All of eight RJ45 ports support IEEE 802.3af/at standard , with a maximum power supply of 30W for a single port and 150W for the whole machine
  • All of eight RJ45 ports support IEEE 802.3af/at standard , with a maximum power supply of 30W for a single port and 150W for the whole machine

Specification of Fiber Media Converter

Power Power Adapter Voltage AC 110V-240V
Consumption 120W/150W

Network Connector

 Network Port PoE Ethernet Port 1~8 Port : 10/ 100/1000Mbps
Ethernet port Uplink Port : 10/ 100/1000Mbps
Fiber Port Uplink Port : 1000M SFP
Transmission Distance

1~8 Port :

1000Mbps:0~100m;

100Mbps: 0~250m;
Uplink Port : 0 ~ 100m
SFP: depend on the SFP transceiver (20km-120km)
Transmission Medium Cat5/5e/6 standard network cable

Network Switch

 Network Standard

IEEE802.3/802.3u,

IEEE802.3x,

IEEE802.ab
Switching Capacity 2.0Gbps
Packet Buffer Memory 1Mbits
Throughput 1.488Mpps
MAC Table 1K
Packet Forwarding rate

100Mbps:14880pps/port

1000Mbps: 148800pps/port
Power Over Ethernet PoE Standard IEEE 802.3af/at
PoE Power Supply 12 45 + ,36 78- , 8 core power supply
PoE Power af=15.4W,at=30W for each port
RJ45 port Port Function

Power priority mechanism,

fast and forward,

MAC automatic learning and aging IEEE802.3X Full-duplex and mode and back-pressure for Half-duplex mode
LED Indicator LED Indicator

LINK/ACT.1000Mbps;

PoE Status Indicator;

Power indicator;Extender
Environmental Working temperature 0℃~55℃
Relative Humidity 20~95%
Storage temperature -20℃~70℃
Mechanical Dimension (L ×W × H) 220mm*140mm*45mm
Color Black
Weight 1.05kg

Application

120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M

Packing box of switch

120W Unmanaged POE Switch 8 PoE 10/100/1000Mbps + 2 LAN 10/100/1000Mbps + 1SFP 100/1000M

FAQ

  1. Are you a manufacturer?

    Yes, we have our production line and R&D team.

    Please visit us via below VR link to see our office and production area.

    https://www.ecer.com/corp/uuu5b8d-industrialnetworkswitch/vr.html

  2. What is the leadtime if I order?

    After receiving the payment, we start production.

    If you are ordering some popular models, we usually got stock. After some testings, we will ship the materials.

    If we do not have stock, production time is usually 3~5 working days for less than 50pcs/pairs.

  3. How will you ship my order?

    We will send the goods by air(DHL, UPS or FEDEX) or by sea(for bulk order)

    It is fine to ship purchased items via customer’s shipping account or forwarder.

    It takes 3~5 calendar days to arrive at local customs for clearance.
