1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
Specifications
Brand Name :
Olycom
Model Number :
OM615-CH1FKM-T/R
Certification :
CE RoHS FCC
Place of Origin :
Shenzhen, China
MOQ :
1 pair
Price :
Negotiable
Payment Terms :
T/T, Paypal
Supply Ability :
1200 pairs per week
Delivery Time :
3~8 working days
Packaging Details :
1 pair in a carton, 1.26kg(G.W)
Product name :
HDMI to fiber extender
Port :
HDMI interface,USB ports
Fiber :
SC, ST FC optional
Dimension :
152.8mm*130mm*28.3mm
Voltage :
12V
Warranty :
1 year
Description

1080P 4K HDMI Optic Fiber Extender

Overview

OLYCOM HDMI video optical converters

  • compress and convert 1080P HD video signal to network signal

  • transmit HD video signals long distance on fiber cable

  • Support HDMI and other HD video signal interface

  • Support all of the video resolution from 640X480 to 1080P

Features

  1. Cascading, broadcast and other transmission ways are available

  2. One to one, one to many, many to one and many to many application mode

  3. Standard TCP/IP network protocol, long transmission distance, Strong anti-interference ability

  4. Support reverse control signal from mouse, keyboard and serial port

  5. Use MJPEG format, reduce transmission bandwidth, to ensure smooth video playback, good color reproduction and short delay time

Technical Parameters

Name

Description

DC

12V1A

F/W

Reset Button

RJ45

Normal network interface, connect with switch or connect transmitter and receiver directly

HDMI/DVI

Transmitter: HD video input port / Receiver: HD video output port

LED

PWR；Video status indicator；Network connection indicator；Fiber indicator

Video Compress Format

M-JPEG: Compress 1080P@60HZ video signal to 50Mbps

Video Interface

HDMI: Support HDMI1.1/1.2/1.3, HDCP1.1/1.2, Compatible with DVI

Protocol

TCP/IP: Standard TCP/IP network protocol

Transmission Delay

70ms: Direct transmission delay less than 70 ms.

Remote Control

UART,USB: RS232, USB

RJ-45 Port

Auto-MDI/MDIX

Video Resolution

VES & CEA-861: 640*480, 720*576, 800*600, 1024*600, 1024*768, 1152*864, 1280*600, 1280*720, 1280*768, 1280*800, 1280*960, 1280*1024, 1440*1050, 1440*900, 1600*900, 1660*1200, 1680*1050, 1920*1080

Audio

Digital Audio: 32khz,44.1khz,48khz.

Fiber Port

SC(ST,FC optional)

Working Temperature

0-70℃

Dimension

152.8mm*130mm*28.3mm

Ordering Details

OM615-CH1RKM-T/R

Compressed HDMI Extender, one RJ45 ports, two USB ports

OM615-CH1R-T/R

Compressed HDMI Extender, one RJ45 port

OM615-CH2RKM-T/R

Compressed HDMI Extender, two RJ45 ports, two USB ports

OM615-CH2R-T/R

Compressed HDMI Extender, two RJ45 ports,

OM615-CH2R2F-T/R

Compressed HDMI Video Optical Converter, two RJ45 ports,two fiber ports

OM615-CH1FKM-T/R

Compressed HDMI Video Optical Converter, one fiber ports, two USB ports

OM615-CH1F-T/R

Compressed HDMI Video Optical Converter, one fiber ports

Application Diagram

1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE

1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE

Product Images

1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE

1080P 4K Kvm HDMI DVI Extender With USB 20km Distance On SC ST FC Fiber CE
