Normally White HSD040I3N1-B00 HannStar Lamp Type WLED Without Driver Outline 112.11×80.51×8.3 mm
Normally White HSD040I3N1-B00 HannStar Lamp Type WLED Without Driver Outline 112.11×80.51×8.3 mm
Specifications
Brand Name :
HannStar
Model Number :
HSD040I3N1-B00
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size :
4.0 inch
Resolution :
320×240
Active Area :
82.08×61.56 mm
Outline :
112.11×80.51×8.3 mm
Contrast Ratio :
350:1 (Typ.)
Frequency :
60Hz
Description

Normally White HSD040I3N1-B00 HannStar Lamp Type WLED Without Driver Outline 112.11×80.51×8.3 mm

HSD040I3N1-B00 Basic Information

Panel Model HSD040I3N1-B00
Panel Brand HannStar
Descrition a-Si TFT-LCD ,4.0 inch, 320×240
Panel Type a-Si TFT-LCD
Operating Temperature -30 ~ 80 °C
Storage Temperature -40 ~ 95 °C
Vibration Resistance 2.9G (28.4 m/s²)

HSD040I3N1-B00 Mechanical Features

Dot Resolution 320(RGB)×240 (QVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 99 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.0855×0.2656 mm (H×V)
Pixel Pitch 0.2565×0.2656 mm (H×V)
Weight 95/105g (Typ./Max.)
Active Area 82.08×61.56 mm (H×V)
Outline Dimension 112.11×80.51 mm (H×V)
Outline Depth 8.0/8.3 (Typ./Max.) mm
Holes & Brackets Face mounting holes (4 pcs) on left, right bracket
Landscape or Portrait Landscape type
Touch Panel Without

We can do for You:

1. Quality Guarantee:

100% original new Hard Disk for you.

2．Fast reply:

Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.

3．Delivery Guarantee:

Large Stock System, We have our own warehouses in Shenzhen and Hong Kong, with comprehensive supply lines.

4．After-Sale Service:

Professional support team to provide effective service, we are young and full of passion!

5. Professional acknowledgement of hard disks to provide customers with effective advice.

We have been in hard disk business for more than 6 years and know the main brands' hard disk very well.

6. Competitive quotation:

Our big customer network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

HSD040I3N1-B00 Optical Features

Display Mode TN, Normally White, Transmissive
Brightness 4700 cd/m² (Typ.)
Contrast Ratio 350 : 1 (Typ.) (Transmissive)
Display Color 16.7M (8-bit)
Color Gamut 45% NTSC (CIE1931)
Response Time 4/12 (Typ.)(Tr/Td)
Viewing Angle 60/60/60/40 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction 4:30 o'clock
White color Chromaticity Wx:0.310; Wy:0.330
White Variation 1.43 (Max.)(9 points)
Sunlight Readable Y

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
HSD050B8W2-A00 HannStar 5.0" 480×854
HSD040B8W3-A00 HannStar 4.0" 480×854
HSD028FAW1-A00 HannStar 2.8" 240×400
HSD097PXN1-A00-0299 HannStar 9.7" 1024×768
HSD097PXN1-A00-0220 HannStar 9.7" 1024×768
HSD020F2NA-A00 HannStar 2.0" 176×220
HSD030FAW1-A00 HannStar 3.0" 240×400
HSD053F8W1-A00 HannStar 5.3" 480×854
HSD101PFW4-A00-0299 HannStar 10.1" 1024×600
HSD080IDW1-A00-0299 HannStar 8.0" 800×480
