QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
Specifications
Brand Name :
TPO
Model Number :
TD028STEB2 TD028TTEB6
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union, Paypal, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
2-3 Working Days after Order Confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Model :
TD028STEB2 TD028TTEB6
Form Factor :
Flat Rectangle Display
Outline Depth :
4.2 (Typ.) mm
Weight :
35g (Max.)
Dot Pitch :
0.060×0.180 mm (H×V)
Pixel Pitch :
0.180×0.180 mm (H×V)
Description

QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6

Main features:

Panel Brand :TPO
Panel Model :TD028STEB2 TD028TTEB6
Panel Type :LTPS TFT-LCD , Panel
Panel Size :2.8 inch
Resolution :240(RGB)×320 , QVGA
Display Mode :TN, Normally White, Transflective
Active Area :43.2×57.6 mm
Outline :52.9×71.7 mm
Surface :
Brightness :150 cd/m² (Typ.)
Contrast Ratio :150:1 (Typ.)(Transmissive) 10:1 (Typ.)(Reflective)
Display Colors :262K (6-bit) , CIE1931 45%
Response Time :35 (Typ.)(Tr+Td)
Viewing Angle :40/45/60/35 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type :4S1P WLED Without Driver
Signal Interface :Parallel RGB (1 ch, 6-bit) , 61 pins
Input Voltage :2.8V (Typ.)(DVDD)


Technical Specifications for TD028STEB2 TD028TTEB6 LCD Panel:
1. Active Area : 43.2×57.6 mm (H×V)
2. Outline Dimension : 52.9×71.7 mm (H×V)
3. Reverse Scan : No
4. Total Power Consumption : 311mW (Typ.)


TPO TD028STEB2 TD028TTEB6 Backlight System

1. Lamp Position : Edge light type
2. Lamp Type : WLED
3. Lamp Amount : 4S1P
4. Lamp Shape : 1 string
5. Lamp Life Time : 10K(Typ.) (Hours)
6. Lamp Voltage : 14.4/16.0V (Typ./Max.)
7. Lamp Current : 20/25mA (Typ./Max.)
8. Lamps Power Consumption : 288mW (Typ.)
9. Interface Type : Included in panel signal interface
10. Lamp Driver Board : No

As one of the leading LCD distributor in China, we are strong at EOL panels and hard to find shortage panels of world famous Brand such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA HITACHI/KOE Etc.

Technical parameters for TPO TD028STEB2 TD028TTEB6 LCD:

QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6QVGA Antiglare 2.8 Inch TFT Colour Display Led Backlight For Advertising TD028STEB2 / TD028TTEB6
