ITD IP65/55/67 Embedded Industrial PC Rugged LED Touch Monitor Solutions Waterproof Box Android PC
ITD IP65/55/67 Embedded Industrial PC Rugged LED Touch Monitor Solutions Waterproof Box Android PC
ITD IP65/55/67 Embedded Industrial PC Rugged LED Touch Monitor Solutions Waterproof Box Android PC
ITD IP65/55/67 Embedded Industrial PC Rugged LED Touch Monitor Solutions Waterproof Box Android PC
Specifications
Brand Name :
ITD/OEM
MOQ :
1PCS
Price :
TBA
Payment Terms :
T/T,PayPal(173515844@qq.com)
Supply Ability :
10000 PCS Per Month
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
Description



ITD IP65/66/67 industrial rugged High-performane LED Touch monitor screen Fanless Embedded computers Display Solutions


The ITD rugged waterproof box Android PC is designed to withstand harsh environmental
conditions such as exposure to water, dust, and extreme temperatures. It is rugged and reliable
computing solution that can be used in a wide range of applications, including industrial
automation, outdoor surveillance, and marine environments. IP65/IP66/IP67 rating indicates that
the box PC is completely protected against dust and can withstand immersion in water up to a
certain depth for a specified amount of time. Rugged IP65/IP66/IP67 waterproof box computer is a
robust and durable computing solution that is designed to withstand harsh environments and
extreme conditions.


FEATURES:

•Robust aluminum alloy enclosure, sealed I/O from particles, water, and corrosive agents
•Full IP65/66/IP67 and sealed with anti-corrosive rubber to providing 360 degree protection
•Rugged aluminum alloy enclosure with high EMC and IP65/IP66/67 NEMA4/4X protection
•High performance ARM based computing capabilities with low power consumption
•Fanless design, anti-Shock and anti-vibration
•CE, FCC, RoHS Compliance


System







 CPU ARM Octa Core RK3588, Cortex-4×A76+4×A55
GPU Mali-G610 MP4 Quade GPU
Supports OpenGL ES3.2 / OpenCL 2.2 / Vulkan1.1, 450 GFLOPS
Chipset Rockchip
SDRAM Default to LPDDR4/LPDDR4x 4GB 64bit LPDDR4/LPDDR4x, Max.
64GB
ROM Default to eMMC 32GB, Max. 128GB
Speakers Optional
Multi Media VPU 8K@60fps H.265/H.264/VP9 Video Decoding NPU
Computing Power; 6Tops, 8K Video Encoding and Decoding
Operating System Android 12
Communication Bluetooth Bluetooth 5.2
GPS Optional
WiFi6 2.4GHz&5GHz,IEEE 802.11b/g/n/AC, (Built-in High-Performance SDIO Interface WiFi6 Module)
4G/5G Optional
Default
Waterproof I/O 		Serial Ports 1 × COM
USB Ports 2 × USB 2.0, Max.: 6× USB 2.0(1× USB 3.0 included)
LAN 1 × RJ45 (10M/100M/1000M Ethernet)
Video Output 1 × HDMI Output
Power 1 × DC9~36V input
Other Power Switch 1 × Power Switch
Breathing Valve 1 × Breathing Valve
Power Input Voltage DC 9~36V
Operation/Power
Saving		 15W
Structure Housing Material Aluminum Alloy, Full CNC Treated, Anodizing and Anti-scratch
Treatment
Color Black or Silver
Mounting Method VESA Mounting 75 ×75mm
Cooling System Die-Casting Aluminum Chassis with Passive Cooling
Environment Considerations Operating Temperature -10~60℃
Storage Temperature -20~70℃
Humidity 10 ~ 90% @ 10C (No condensation)
Vibration 50 ~ 500 Hz, 1.5G, 0.15mm peak to peak
Shock 10 G/Peak (11 ms)
