OEM 13.3”PCAP Touch Panel PC with RFID & QR & Printer, Intel J6412 Industrial HMI LCD Touch Display Panel PC Touch Screen All-In-One Mini Computer
OEM 13.3”PCAP Touch Panel PC with RFID & QR & Printer, Intel J6412 Industrial HMI LCD Touch Display Panel PC Touch Screen All-In-One Mini Computer
Specifications
Brand Name :
ITD/OEM
Model Number :
ITD08PPCT5B-xxxxx_V2
Certification :
CE,FCC, RoHS Compliance
Place of Origin :
China
MOQ :
1PCS
Price :
TBA
Payment Terms :
T/T,PayPal(173515844@qq.com)
Supply Ability :
10000pcs per month
Delivery Time :
10 working days
Packaging Details :
1-5pcs/CTN, Safe, Firm
Description



ITD 13.3”PCAP Touch Panel PC with RFID & QR & Printer, Intel J6412 Industrial HMI LCD Touch Display Panel PC Touch Screen All-In-One Mini Computer


INTRODUCTION:

The ITD industrial multi-touch screen panel PC is fully-integrated‚ that combines high-performance
Intel Celeron J6412 Processor Quad-core 2.0GHz with Projected Capacitive Touch in a sleek
commercial-grade TFT-LCD flat panel with flat front surface design. This advanced panel PC
integrates RFID, QR code scanning, and printing capabilities, making it ideal for applications
requiring secure identification, data processing, and on-the-spot documentation. With its durable
construction and responsive touchscreen, this all-in-one device is perfect for streamlining
operations in manufacturing, logistics, retail and other sectors.


FEATURES

•Easy-to-clean, true flat front surface without dust and debris building-up at the edge and corners
•Flexible, reliable, and ruggedized touch screen computers for open platform HMI/SCADA
•RFID/NFC reader, thermal printer, QR reader integrated
•Responds to a light touch to activate response even in rain
•Ruggedized levels of NEMA 4, IP52, IP54, and IP65 ratings for front panel
•Aluminum bezel with steel back chassis designed for harsh and industrial environments
•CE, FCC, RoHS Compliance


OPTIONALS


• AR/AG/AF Tempered Glass, Optical Bonding
• DC9~36V input, AC100~240V input
• WiFi, Bluetooth, 4G/5G Module, GPS

• Camera, Speakers, Fingerprint, MIC Built-in

•VESA Brackets, Embedded/Panel Mounting


SYSTEM


 ITD13PPCT5XJ6-RFID-QR-PR
Size/ Aspect Ratio 13.3”/16:9
Active Area/ Pixel Pitch 293.76(W)×165.24(H)mm/ 0.153×0.153 mm
Resolution/ Colors 1920×1080/16.7M
Brightness/ Contrast 300cd/㎡/800:1
Response Time/ Viewing Angle 30ms/85/85/85/85
Light Source LED Backlight with 30000Hours’Lifetime
CPU Intel® Celeron J6412 2.0 Processor
BIOS AMI
Chipset Intel Elkhart Lake
Graphic Chipset Intel UHD Graphics
Memory

J6412/N97: 1 × DDR4 SODIMM, Max.16GB

1 × SO-DIMM DDR4 2933/2666MHz Max. 16GB

Storage

1 × SATA3.0

Expansion Slots

1 × M.2 KeyB, Supports SATA SSD/4G/5G
Module
1 × M.2 KeyE, Supports Wifi6+Bluetooth
Ethernet 1 × Realtek RTL8111 Gigabit LAN (Dual LAN
optional)
I/O

1 × COM (Max. 6 × COM)
2 × USB 3.2, 2 × USB 2.0(Max. 6 × USB 2.0)
1 × VGA Output

1 × HDMI Output
Realtek ALC662 Line-Out/ /MIC IN
1 × CMOS
Input Voltage

DC 12V

Operation/Power Saving

25W
Operating Temperature

0~50℃

Storage Temperature

-20~60℃
Relative Humidity

10%~90%(Non Condensing)

OS Support

Windows 7/Windows Embedded/Windows 10/Windows IoT/Windows 11/Linux
