10.1” Touch Android Tablet PCAP Zero Bezel Touch LCD Panel PC All In One with Halo LED light strip
10.1” Touch Android Tablet PCAP Zero Bezel Touch LCD Panel PC All In One with Halo LED light strip
Specifications
Brand Name :
ITD/OEM
Model Number :
ITD101PPCT5KE1-DC
Certification :
CE,FCC, RoHS Compliance
Place of Origin :
China
MOQ :
1PCS, No MOQ
Price :
TBA
Payment Terms :
T/T,PayPal(173515844@qq.com)
Delivery Time :
10-15 Business days
Description

INTRODUCTION

ITD 10.1” multi-touch screen HMI comfort panel PC is fully-integrated‚ with halo LED indicator, multi
capacitive touch screen combines high-performance ARM Quad-Core Cortex-A17 Processor RK3288
1.82.0GHz, and Projected Capacitive Touch (PCT or PCAP) Technology in commercial-grade LCD flat
panels, combined with a smart card reader and web camera with sleek and flat front surface
industrial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10
multi-touch interactive experiences. The ITD multi-touch HMI comfort panel PC specifically suited
for various smart interactive applications.


FEATURES

▪ Easy-to-clean, true flat front surface without bezel
▪ RFID/NFC/camera Modules Built-in
▪ Ten independent touch points with anti-vandalism & scratch
▪ Responds to a light touch to activate response
▪ Eliminates dust and debris build-up at the edge and corners of the display
▪ Provides improved power efficiency and reduced consumption
▪ Halo LED indicator integrated
▪Plastic housing equipped with light weight
▪ CE, FCC, RoHS Compliance



SPECIFICATION

Panel Cell Type/Glass Surface TFT
Size 10.1”
Aspect Ratio 16:10
Active Area 216.96(W) × 135.6(H)mm
Pixel Pitch 0.1695× 0.1695mm
Native Resolution 1280 × 800(1920×1200 optional)
Colors 16.7M
Brightness 300nits
Contrast 800:1
Response Time 30ms
Viewing Angle(Typical) 85/85/85/85
Light Source LED Backlight with 30000Hours’Lifetime
Native Resolution/Colors 1280×800/16.7M
Response Brightness/Contrast 350cd/㎡(500~1000 cd/㎡optional)/800:1
Viewing Angle(Typical) 85/85/85/85
Light Source LED backlight with 50000hours’lifetime
System CPU: ARM Quad Core RK3288, Main CPU frequency:1.8GHz
GPU: Mali-T764 GPU
SDRAM: 2G; 4G Optional
Flash: 8G: 16G/32G/64G Optional
OS: Android 8.1/9.1 Bluetooth: included
Audio Format: Supports MP3/WMA/AAC etc.
Video Format: Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, VC1, RV etc., up to
1080p
Photo Format: Supports JPEG
WIFI: 802.11b/g/n
2 × 2W Speakers Built-in
2MP Front Camera Built-in
Input / Output 1 × 3.5mm Earphone Jack
2 × USB Host 2.0, 1× mini-USB OTG
1 × RJ45 (10M/100M Ethernet)
1 × SD Card Slot up to 32GB
1 × DC Jack
1 × PoE (power input, POE 802.3af (15W) optional
Operating Temperature -10~60℃
