18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
18.5 industrial pcap touch panel PC with LED light frame indicator IP65 front
Specifications
Payment Terms :
T/T,PayPal(173515844@qq.com)
brightness :
300 nits
Memory :
2GB,4GB,8GB,16GB
Supply Ability :
10000PCS/Month
Active area :
408.96(H) × 230.04(V)mm/0.213 × 0.213mm
Model Number :
ITD18PPCT5KE3-DC
Price :
TBA
CPU :
RK3399,RK3568,RK3588, Intel N100
Power input :
DC12V
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
MOQ :
1PCS
Delivery Time :
7-10 Business Days
Storage :
8GB~64GB
Certification :
CE, FCC, RoHS
Place of Origin :
China
Brand Name :
ITD/OEM
Description

18.5" industrial pcap touch panel PC with LED light frame indicator IP65 front

ITD’s Zero-Bezel LED-Framed PCAP Touch Panel PC is a sleek and durable industrial computing solution designed for seamless integration across various applications. Featuring a true flat, zero-bezel design, it enhances usability while offering multi-touch capacitive touch technology for a smooth and responsive user experience. This high-performance touch panel PC is available with optional ARM-based or x86-based Intel processors, catering to different computing requirements, from energy-efficient edge computing to high-performance industrial automation. Its LED-framed design not only adds a modern aesthetic but also improves visibility in low-light environments. Built for industrial environments, it boasts rugged construction, IP-rated front panel protection, and fanless cooling, ensuring reliable performance in harsh conditions. Whether deployed in factory automation, kiosks, medical devices, or retail, ITD’s Zero-Bezel PCAP Touch Panel PC delivers the perfect combination of durability, efficiency, and cutting-edge touch technology.

SPECIFICATION of 18.5" Industrial Panel PC

Panel Cell Type/Glass Surface TFT
Size/ Aspect Ratio 18.5”/16:9
Active Area/ Pixel Pitch 408.96(H) × 230.04(V)mm/0.213 × 0.213mm
Native Resolution/ Colors 1920×1080/16.7M
Brightness/ Contrast 300cd/㎡/1000:1
Response Time/ Viewing Angle(Typical) 30ms/85/85/85/85
Light Source LED Backlight with 30000Hours’Lifetime

SYSTEM

Item ARM Solution X86 Solution
CPU ARM Quad Core Cortex-A17 RK3288, 1.8GHz (RK3399/RK3568/RK3588 optional) Intel® N100
Chipset Rockchip Intel SoC
Memory 2GB; 4GB/8GB Optional DDR4 SODIMM×1, Max.16GB
Storage 8GB; 16GB/32GB/64GB/128G Optional 1×mSATA, 1×SATA; Default to 64GB SSD
Graphics Supports max. 4K resolution Intel UHD Graphics (By CPU)
I/O

1 × HDMI Output; 2 × USB; 1 ×Type C; 1 × COM,

1 × TF Card Slot; 1 × Audio IN/OUT

1 × DC Jack

1 × HDMI Output; 3 × USB 3.0; 1 × Type C

1 × Audio IN/OUT

1 × Power Switch, 1 × DC Jack
LAN 1×10/100/1000Mbps Ethernet 1× 10/100/1000Mbps Ethernet
OS Android 7.1/8/10/11/12/14, etc Win10/11/Linux

GENERAL

Power Input Voltage DC 12V 2.0
Operation/Power Saving 18~25W
Environment Considerations Operating Temperature -10~50℃
Storage Temperature -20~60℃
Relative Operating Humidity 10%~80%(Non-Condensing)
Relative Storage Humidity 10%~85%(Non-Condensing)
18.5
18.5
18.5
18.5
