1024x768 350nits Open Frame Panel PC ARM Based RK3288 Linux Ubuntu 18.04
1024x768 350nits Open Frame Panel PC ARM Based RK3288 Linux Ubuntu 18.04
1024x768 350nits Open Frame Panel PC ARM Based RK3288 Linux Ubuntu 18.04
1024x768 350nits Open Frame Panel PC ARM Based RK3288 Linux Ubuntu 18.04
Specifications
Brand Name :
ITD/OEM
Model Number :
ITD10PPCT5FJ2
Certification :
CE, FCC, RoHS
Place of Origin :
China
MOQ :
1PCS
Price :
TBA
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
10000PCS/Month
Delivery Time :
15-20 Business Days
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
Native resolution :
1024x768
Brightness :
350nits
Processor :
ARM RK3288, RK3399 Android 9/10/11,Ubuntu
touch panel :
capacitive
optional :
4G, BT, WIFI
I/O :
USB, COM, HDMI, Audio, LAN, DC 12V input
Operating Temperature :
-20~70℃
Storage Temperature :
-20~70℃
Material :
Steel Housing
MTBF :
50000hours
Description

10" open frame panel PC ARM based RK3288 Androd 9 Linux Ubuntu 18.04

FEATURES

• Flexible, reliable, and ruggedized for open platform HMI/SCADA
• Energy-efficient and fan-less HMI Systems
• Low-cost solution with high cost-efficient
• All steel construction designed for harsh and industrial environments

• Flexible, easy configuration and integration
• CE, FCC, RoHS Compliance

OPTIONALS

• Anti-Glare / Anti-Reflective Tempered Glass • High Brightness, Optical Bonding
• Resistive, IR, SAW, PCAP, SLW • WIFI, 3G, 4G
• Web camera, Speakers, RFID, NFC, Fingerprint, QR Reader, Thermal printer, GPS etc. • DC9-36V input, AC100-240V input

DISPLAY

Panel Cell Type/Glass Surface TFT
Size/ Aspect Ratio 10.4”/4:3
Active Area/ Pixel Pitch 211.2(W) x 158.4(H)mm/0.297 × 0.20625mm
Native Resolution/ Colors 1024 x 768/262K/16.7M
Brightness/ Contrast 350cd/㎡/900:1
Response Time/ Viewing Angle(Typical) 16ms/75/75/75/75
Light Source LED Backlight with 50000Hours’Lifetime

SYSTEM

Item Android Solution
CPU ARM Quad Core Cortex-A17, 1.8GHz
Chipset RK3288(RK3399 optional)
Memory 2GB; 4GB Optional
Storage 8GB: 16GB/32GB/64GB Optional
Graphics Supports max. 4K resolution
I/O 1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 2 × COM; 1 × TF Card Slot Support 8~128GB

LAN 1 x 10/100/1000Mbps Ethernet
OS Android 9, Linux Ubuntu 18.04

GENERAL

Power Input Voltage DC 12V 2.0
Operation/Power Saving 15~30W
Environment Considerations Operating Temperature -10~60℃ (-20~70℃ optional)
Storage Temperature -20~70℃
Relative Humidity 10%~90%
