20W 350nits Industrial Touch Screen PC 13.3 1600MHz With -20~70℃
20W 350nits Industrial Touch Screen PC 13.3 1600MHz With -20~70℃
20W 350nits Industrial Touch Screen PC 13.3 1600MHz With -20~70℃
20W 350nits Industrial Touch Screen PC 13.3 1600MHz With -20~70℃
Specifications
Brand Name :
ITD/OEM
Model Number :
ITD13PPCT5Xxx
Certification :
CE, FCC, RoHS
Place of Origin :
China
MOQ :
1PCS
Price :
TBA
Payment Terms :
T/T, PayPal(173515844@qq.com)
Supply Ability :
10000PCS/Month
Delivery Time :
7-10 Business Days
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
Native resolution :
1920x1080
Brightness :
350nits, 500 ,1000nits optional
Processor :
RK3288, RK3399, Intel J1900, Intel i3/i5/i7
touch panel :
capacitive/resistive
Mounting method :
panel mount,VESA
I/O :
USB, COM, HDMI, Audio, LAN, GPIO
Operating Temperature :
-20~70℃
Storage Temperature :
-20~70℃
Material :
Steel Housing, aluminum front bezel HeatSink
Warranty :
2 years
MTBF :
50000hours
Description

marine panel PC industrial touch screen 13.3" with -20~70℃

Panel Cell Type/Glass Surface TFT
Size/ Aspect Ratio 13.3”/16:9
Active Area/ Pixel Pitch 293.42(H)x 164.97(V)mm/0.2235 × 0.2235mm
Native Resolution/ Colors 1920 x 1080/262K
Brightness/ Contrast 1000cd/㎡/700:1
Response Time/ Viewing Angle(Typical) 16ms/89/89/89/89
Light Source LED Backlight with 50000Hours’Lifetime

SYSTEM

Item Android Solution X86 Solution 1 X86 Solution 2
CPU ARM Quad Core Cortex-A17, 1.8GHz (RK3399 optional) Intel® Celeron J1900 2.0GHz Intel® Core i3/i5/i7
Chipset RK3288 Intel Bay Trail SoC Intel SoC Chipset
Memory

2GB; 4GB Optional

Dual Channel, DDR3 1333/1600MHz Memory,

Max.8GB

 2 x DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB
Storage

8GB: 16GB/32GB/64GB Optional

 1 x SATA, 1 x mSATA, Default to 64GB SSD 1 x SATA, 1 x mSATA, Default to 64GB SSD
Graphics Supports max. 4K resolution Intel HD Graphics (By CPU) Intel HD Graphics (By CPU)
I/O 1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 2 × COM; 1 × TF Card Slot Support 8~128GB

1 x VGA Output; 1 x HDMI Output; 2 x USB 3.0; 2 x USB 2.0 max. 6; COM port(optional); 1 x Realtek ALC662

Line-Out /MIC IN

1 x VGA Output; 1 x HDMI Output; 2 x USB 3.0; 2 x USB 2.0 max. 6; 2 x COM max. 6; 1 x Realtek ALC662

Line-Out /MIC IN
LAN 1 x 10/100/1000Mbps Ethernet 1 x 10/100/1000Mbps Ethernet 1 x 10/100/1000Mbps Ethernet
OS Android 6.0 (Android 7.0 optional) Windows 7/8/10, Linux Windows 7/8/10, Linux

GENERAL

Power Input Voltage DC 12V 2.0
Operation/Power Saving 20~45W
Environment Considerations Operating Temperature -10~60℃
Storage Temperature -20~70℃
Relative Humidity 10%~90%
Order Information 13.3” Flat Bezel Marine Panel PC 1000nits with PCAP Touch RK32880/ITD13PPCT5HBXE2
13.3” Flat Bezel Marine Panel PC 1000nits with Resistive Touch RK3288/ITD13PPCT1HBXE2
13.3” Flat Bezel Marine Panel PC 1000nits with Tempered Glass RK3288/ITD13PPCG1HBXE2
13.3” Flat Bezel Marine Panel PC 1000nits with PCAP Touch J1900/ITD13PPCT5HBXJ2
13.3” Flat Bezel Marine Panel PC 1000nits with Resistive Touch J1900/ITD13PPCT1HBXJ2
13.3” Flat Bezel Marine Panel PC 1000nits with Tempered Glass J1900/ITD13PPCG1HBXJ2
13.3” Flat Bezel Marine Panel PC 1000nits with PCAP Touch i3/ITD13PPCT5HBXI3
13.3” Flat Bezel Marine Panel PC 1000nits with Resistive Touch i3/ITD13PPCT1HBXI3
13.3” Flat Bezel Marine Panel PC 1000nits with Tempered Glass i3/ITD13PPCG1HBXI3
13.3” Flat Bezel Marine Panel PC 1000nits with PCAP Touch i5/ITD13PPCT5HBXI5
13.3” Flat Bezel Marine Panel PC 1000nits with Resistive Touch i5/ITD13PPCT1HBXI5
13.3” Flat Bezel Marine Panel PC 1000nits with Tempered Glass i5/ITD13PPCG1HBXI5

20W 350nits Industrial Touch Screen PC 13.320W 350nits Industrial Touch Screen PC 13.3
