Specifications
Model Number :
A-I33S
Rate Voltage :
400/230V
MOQ :
1 Set
Supply Ability :
1000 Set / Months
Delivery Time :
30 days
Max. Power :
26.4kW / 33kVA
Engine Model :
JE493ZDB-04
Alternator Model :
ASF184G
Place of Origin :
China
Alternator Brand :
Hosem
Brand Name :
Hosem
Payment Terms :
L/C, T/T
Frequency :
50Hz
Engine Brand :
Isuzu
Model :
A-I33S
Certification :
CE/ ISO
Packaging Details :
Plastic films or ply-wood
Rate Power :
24kW / 30kVA
Rate Current :
43.3 A
Description

Reliable Isuzu Diesel Generator with JE493ZDB Engine for Backup & Commercial Power

The Reliable Isuzu Diesel Generator Set powered by the JE493ZDB engine is engineered to deliver stable, fuel-efficient, and long-lasting power for a wide range of applications. Designed with durability and performance in mind, this generator set provides dependable electricity for both backup power and continuous operation in commercial and light industrial environments.

The JE493ZDB Isuzu engine is known for its smooth performance, low fuel consumption, and easy maintenance. Combined with a high-quality alternator and intelligent control system, the generator ensures consistent voltage output and reliable operation even under varying load conditions.

Whether used in urban installations or remote locations, this generator set offers a practical and cost-effective power solution backed by proven Isuzu technology.

Key Features

  • Reliable Isuzu JE493ZDB Engine

Proven durability, low fuel consumption, and stable performance

  • Efficient & Stable Power Output

High-quality alternator ensures consistent voltage and frequency

  • Compact & Practical Design

Space-saving structure suitable for various installation environments

  • Smart Control System

Digital controller with monitoring, alarms, and protection functions

  • Low Maintenance Requirements

Easy access design for fast servicing and reduced downtime

Reliable Isuzu Diesel Generator with JE493ZDB Engine for Backup & Commercial Power

Specification of Isuzu Diesel Generator

Generator Set Specification
Model A-I33S
Max. Power kVA 33
kW 26.4
Rate Power kVA 30
kW 24
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 43.3
Fuel Tank Capacity L 60
Dimension For Open-type Genset mm 1560 X 680 X 1350
Weight For Open-type Genset kg 630
Dimension For Soundproof Genset mm 2050 X 860 X 1100
Weight For Soundproof Generator kg 960
Noise Level for Soundproof Generator at 7M dBA 70
Battery One of Free Maintenance Battery

Engine Specification
Engine Manufacturer Isuzu Engine Co., Ltd.
Engine Brand Isuzu
Engine Model JE493ZDB-04
No. of Cylinder 4 Cylinder in line
Aspiration Turbocharged
Governor Mechanical
Engine Max. Output Power kW 31
Displacement L 2.8
Compression Ratio 18.2 : 1
Starting Voltage V 12
Bore mm 93
Stroke mm 102
Lubrication Oil Capacity L 5.6
Intake Air Flow M3/Min 18.2
Fuel Consumption at 100% Load L/H 8.254216867

Alternator Specification
Alternator Manufacturer Fuzhou Hosem Power Co., Ltd.
Alternator Model ASF184G
Alternator Brand Hosem
Rate Output kVA 32
Frequency Hz 50Hz
Altitude M 1000
Insulation Class H
Phase 3 Phase
Working Temperature without power decrease ≤40℃
Working Altitude without power decrease ≤1000m
Automatic Voltage Regulation SX460
Protection Grade IP23
Alternator for optional Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional

Reliable Isuzu Diesel Generator with JE493ZDB Engine for Backup & Commercial Power

Control Panel Specification
Controller Brand Smartgen
Controller Model HGM6120N
Breaker Brand Delixi
Breaker Capacity (A) 63
Battery Charger Smartgen Model BAC06A
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Reliable Isuzu Diesel Generator with JE493ZDB Engine for Backup & Commercial Power

Applications

The Isuzu diesel generator set is designed to deliver reliable and fuel-efficient power across a wide range of commercial, industrial, and remote applications. In commercial facilities such as offices, retail stores, restaurants, hotels, and supermarkets, it provides dependable backup power to keep lighting, HVAC systems, security equipment, and essential business operations running smoothly during unexpected power outages.​


For construction sites and infrastructure projects, the generator supplies stable electricity for power tools, welding equipment, site lighting, and temporary offices, ensuring continuous productivity even in areas without access to the utility grid. It is also an excellent choice for warehouses, workshops, and small manufacturing facilities that require consistent power for machinery and daily operations.​


In residential communities, apartment buildings, and housing developments, the generator serves as a reliable emergency power source for lighting, water pumps, elevators, and security systems, helping maintain essential services during grid failures. Additionally, it is widely used in telecom base stations, farms, irrigation systems, and remote installations where dependable power is critical. Thanks to its compact design, low fuel consumption, and easy maintenance, the Isuzu diesel generator set offers a cost-effective and long-lasting power solution for users seeking reliable performance with lower operating costs.

FAQ – Isuzu Diesel Generator Set

Q1: Is this generator suitable for home or small business use?

A1: Yes. This generator is ideal for homes, shops, and small offices, providing reliable backup power for essential equipment during outages.

Q2: How fuel-efficient is the JE493ZDB Isuzu engine?

A2: Isuzu engines are well known for their fuel efficiency, helping reduce long-term operating costs while maintaining stable performance.

Q3: Can this generator run continuously for long periods?

A3: Yes. When properly maintained and operated within recommended load limits, it can be used for both standby and extended running applications.

Q4: Can the generator be customized?

A4: Yes. Options include soundproof canopy, ATS (Automatic Transfer Switch), voltage customization, and different alternator brands.

Q5: What maintenance is required?

A5: Routine maintenance includes oil changes, filter replacement, and system checks. The generator is designed for easy access to key components.

Looking for a reliable Isuzu diesel generator for your project or business?

Contact our team today for expert recommendations tailored to your power needs.
