High Efficient Fluidized Bed Granulator Machine For Making Impact Granules

Fluid bed Granulation Dryer Overview:
Fluid bed dryer granulator is a set of mixing, granulating, drying in the same airtight container once completed equipment (i.e., one-step granulator).

Fluid bed dryer granulator Working principle: Material powder particles, in the raw material container (fluidized bed) in the annular fluidization state, by the purified heating air preheating and mixing, the Adhesive table solution Atomization spray into, so that a number of particles gathered into a binder containing aggregates, due to the continuous drying of hot air materials, water evaporation in the mission grains, the viscosity of the table agent solidification, this process is repeated
To form an ideal, homogeneous porous spherical particle.

Fluid bed dryer granulator Features: Boiling granulating machine is easy to operate, easy to clean, easy to repair, can be granulation and can be quickly dried. Granulation, mixing and drying are done in the same confined room, preventing contact with the outside world and causing pollution.
Ensure that the internal quality of the drug particles conforms to the "GMP" requirements. Boiling granulating Machine Contact material parts are made of 1cr18ni9ti stainless steel.
The machine heat is divided into steam heating and electric heating, the control part of the ordinary type and computer type, any user choice.
Through powder granulation, improve fluidity, reduce dust flying;
The dissolution properties of the powders were improved by granulation.
Mixing, granulating, drying in a machine to complete one-step granulation;
The use of antistatic filter cloth, equipment operation safety;
Set the pressure relief hole, the equipment personnel is not harmed in the event of explosion;
Boiling granulating machine equipment without dead angle, loading and unloading material is light and fast, flushing clean, meet the GMP standard.

Fluid bed dryer granulator Application range:
Granulation in the pharmaceutical industry: Tablets granules, granules granules, Capsules granules.
Food industry granulation: cocoa, coffee, milk powder, granule juice, condiments and so on.
Other industries: Pesticides, feed, fertilizers, pigments, dye chemicals, powder or granular wet material drying. Coating: granule, pill protective layer, preparation color, slow release, film, enteric coating and so on.

Technical Parameter

Note:Model FG can not be equipped with granulating part.
