Semolina Purifier Machine 2*0.25kw Grain Milling Equipment
Semolina Purifier Machine 2*0.25kw Grain Milling Equipment
Semolina Purifier Machine 2*0.25kw Grain Milling Equipment
Semolina Purifier Machine 2*0.25kw Grain Milling Equipment
Specifications
Brand Name :
CTGRAIN
Model Number :
FQFD
Certification :
CE / ISO
Place of Origin :
Zhengzhou, Henan Province
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Sets per Month
Delivery Time :
20 working days
Packaging Details :
Nude packing in Full Container Loading or Fumigation wooden case for LCL.
Name :
FQFD 2*0.25kw Semolina Purifier Machine Grain Milling Equipment
Other Name :
Purifier Used In Flour Mill Plant
Color :
White And Green
Type :
FQFD 60 x 2 x 3
Application :
Improve Grain Flour Quality
Warranty :
12 Months
Description

FQFD 2*0.25kw Semolina Purifier Machine Grain Milling Equipment

Purifier Technical Parameter List :

Type FQFD 60 x 2 x 3
Capacity 1800 - 3500 kg / h (Coarse)
Power 2 x 0.25 kW
Amplitude 8.5 - 9 mm
Frequency 590 Times/min
Aspiration Volume 55 - 90 m3 / min
Shape Size 2700 x 1500 x 1700 mm
Weight 1100 kg

Cleaning machine is widely used in modern flour mills for cleaning and grading of coarse flour and intermediate materials. It is suitable for the production of coarse flour in hard flour mill.

Purifier Working principle:

Materials are evenly distributed on the screen surface through feeding gate, and screen frame is divided into three layers. When the materials are screened, the air flow blows up the particles with the lightest specific gravity from the bottom up, then taken away by air flow through ventilation hood. Lighter materials are discharged out through port on the screen, and clean powder particles would pass through screen holes. The materials under the screen are accumulated in the conveying tank based on quality requirements.

Purifier Features:

  • Machine is driven by vibration motor, combined with wind blowing and screening for ideal classification effect. With more competitive screening rate and ash reduction rate compared with other equipment.
  • The screen surface is cleaned by brush to prevent screen blockage and ensure screening effect.
  • Each supporting point of equipment adopts rubber spring or rubber bearing for less maintenance. Thus equipment can work stably with characters of high durability, shock absorption and noise free.
  • The suction capacity of each chamber can be adjusted through total air volume and air chamber.
