IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable
Specifications
Brand Name :
Hwatek
Model Number :
IEC 62893-4-1
Certification :
IEC
Place of Origin :
China
MOQ :
1000m
Price :
To be negotiated
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
100KM per month
Delivery Time :
4 Weeks
Packaging Details :
Packed in reels
Conductor :
Bared Copper
Insulation :
EVI-2
Jacket :
EVM-1
Cable Shape :
Round
Application :
Industrial, comsumer electrics, medical, EV Charging, Green Energy etc
Packing :
Packed in reels
Volatge :
1500V DC
Temperature :
-40~90℃
PN :
HT2504389
Description

IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

Construction
Conductor
Cross section A:2C×50.0mm2 B:1C×25.0mm2 C:3×2C×0.75mm2
Construction 1596/0.20mm 798/0.20mm 40/0.15mm
+Tinsel+Kevlar
Strand Dia.(Ref.) 9.90mm 7.10mm 1.30mm
Insulation EVI-2
Nom.Thickness 1.10mm 1.00mm 0.50mm
Min.Thickness 0.90mm 0.85mm 0.35mm
Insulation Dia. 12.40±0.40mm 9.20±0.30mm 2.35±0.15mm
Insulation colour 1.red 2.black B.yellow/green C1.violet&white C2.orange&blue C3.gray&brown
Twisted pair / / 4.7mm
Filler PP rope
Material Non-woven
Assembly 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W
Jacket EVM-1
Nom.Thickness 2.20mm
Min.Thickness 1.77mm
Outer Dia. 32.00±1.00mm
Colour Black

IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

Conductor Bared copper stranded
Cross section 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W
Construction 1596/0.20mm ,798/0.20mm,40/0.15mm
Elongation ≥100%
Aged condition 110℃×168H
Insulation EVI-2
Nom.Thickness 1.00 mm
Min.Thickness 0.85 mm
Insulation Dia.12.40±0.40mm

nsulation: :red, black

Jacket EVM-1
Reference standard:IEC standard
Nom.Thickness 2.2 mm
Outer Dia. 32.00±1.00mm
Colour per request

UL758-E258652-20060111A-CertificateofCompliance(2)...

Electric Performance
Rated Temperature -40~90℃
Voltage rating 1500V DC
Max.conductor DC resistance(20℃) A:0.423Ω/km B:0.848Ω/km C:27.4Ω/km
Dielectric Strength AC 3.5kV/5min

IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg CableIEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg CableIEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.

Certificates
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

Production Progress

IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

Shipping
IEC 126 Standard Bared Copper Stranded 2C × 50 mm2 + 25 mm2 + 6C × 0.75 mm2 1500V DC CPE Jacket 90 Deg Cable

FAQ
1. Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2. Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3. Q:Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
4. Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5. Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
