Flexible EV Charging Cable with Low Temperature Resistance (-40ºC) and Abrasion Resistant TPE/PVC Insulation for Electric Vehicles

Specifications

MOQ :

1,000 Meters

Price :

US $0.5-5 / Meter

Model NO. :

UL62

Production Capacity :

20km/Day

Rated Temperature :

80ºC~105ºC

Rated Voltage :

450/750V

Conductor Material :

Tinned or bare copper

Insulation Material :

TPE or PVC

Jacket Material :

TPE or PVC

Low Temperature Resistance :

-40ºC

Reference Current :

300A, 270A, 220A, 180A, 125A, 100A, 95A

Wire Configuration :

2x120mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x95mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x70mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x50mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x35mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x25mm²+25mm²+2x4mm²+2P(2x0.75mm²), 2x20mm²+25mm²+2x4mm²+2P(2x0.75mm²)

Color :

Orange

Oil Resistance :

Good

Pressure Resistance :

Good

Abrasion Resistance :

Good

Flexibility :

Flexible

Description

Application:connection wire between EV charging equipment and EV,Like variety of EV,charging station,charging pile.
Application standard:UL62
Product character:Cable flexible and easily install,good resistant to oil,pressure,abrasion and -40ºC low temperature.
Construction:
Tinned or bare copper
Insulation material:TPE or PVC
Jacket material:TPE or PVC
Technical parameter:
Rated temperature: 80ºC~105ºC
Rated Voltage:450/750V
Remark:Similar specifications can be designed according to customer requirements.

International specification of charging pile system wire	Rated voltage	Reference current	Color
2x120mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	300A	Orange
2x95mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	270A	Orange
2x70mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	220A	Orange
2x50mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	180A	Orange
2x35mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	125A	Orange
2x25mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	100A	Orange
2x20mm²+25mm²+2x4mm²+2P(2x0.75mm²)	450/750V	95A	Orange

Company Profiles:
Founded in 2004 with 16 years of development, we Hwatek established our new plant Nantong Hwatek Wires & Cable Co., Ltd in 2020. Located in Nantong City, Jiangsu Province, our new plant covers 34,000 square meters with 100 million investment.
We are dedicating to R&D and produce various wires and cables like industrial control, communication instruments, medical control, green energy EV and special wires and cables etc. OEM & ODM is also available.
Our Nantong Plant has passed ISO9001, ISO14001, IATF16949, ISO13485 quality system certification. All the ranges of our wires and cables are CCC, UL, CUL, CE, CSA ,TUV,DEKRA,IEC,CQC or ETL qualified. With the company principle 'Profession, Integrity, Eco Friendly and Win-win', we are equipped with a comprehensive sales network to serve customers in various fields around the world. Flexible EV Charging Cable with Low Temperature Resistance (-40ºC) and Abrasion Resistant TPE/PVC Insulation for Electric Vehicles

Frequently Asked Question:
1.Q:What can you supply?
   A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2.Q: What are the certificates do you get?
   A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3.Q:Can we get samples before ordering?
   A:Yes, we are willing to arrange samples for you.
4.Q: What's your lead time?
   A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5.Q. How can you guarantee the product quality?
   A: Always a pre-production sample before mass production and final Inspection before shipment.
