Anti Static Plain Woven Stainless Steel Wire Mesh For Electroplating Industry

Specifications

Brand Name :

BJPFM

Model Number :

PFM-SSFM-PW

Certification :

SGS FDA

Place of Origin :

China

MOQ :

Price :

$3.5 - $20.5/Square Meter

Payment Terms :

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability :

5000 Meter/Meters per Month

Delivery Time :

5-8 work days

Packaging Details :

Kraft paper inside and air bubble film outside, then be put into a wooden case.

Material :

SS 304 316 Stainless Steel Wire

Weave Style :

Plain Woven

Hole shape :

Square Hole or rectangular hole

Mesh :

1-635mesh

Wire Diameter :

0.018-2.03mm

Length :

1-30m

Width :

0.9m, 1m, 1.2m etc

Color :

Silver

Business type :

factory

Description

304 316 Plain Woven Stainless Steel Filter Wire Mesh Screen

Name: Anti Static Plain Woven Stainless Steel Wire Mesh For Electroplating Industry
Brand: BJPFM
Price: 3.5 USD

1. Stainless Steel Filter Mesh Description

The plain weave stainless steel filter has the characteristics of stable and fine filtration performance.

We can supply stainless steel mesh with material SS 304, 304L, 316, 316L, etc. The mesh range is from 1x1 mesh/inch to 635x635 mesh per inch.
We can also design and manufacture various types of stainless steel mesh products according to user needs.

Anti Static Plain Woven Stainless Steel Wire Mesh For Electroplating Industry

2. Stainless Steel Filter Mesh Features

1. High tension: Much higher tension than common polyester mesh and smooth tension

2. Super-precision: Uniform wire diameter and aperture with extremely low difference

3. Low elongation: Very small elongation of wire mesh at high tension

4. Antistatic: Avoid the effects of static for print to ensure the safety of printing

5. High elasticity: The wire mesh will not lose elasticity at extreme tension

6. Hot melt: Special features of stainless wire mesh. Suitable for hot melt ink

7. High corrosion resistance: The excellent corrosion resistance exceeds polyester fiber

8. Good solvent resistance: can avoid the effects of any solvent

3. Stainless Steel Filter Mesh Specification

Stainless Steel Square Woven Mesh
Weave Type	Mesh Count	Wire Dia. (Inch)	Width of Opening (Inch)	Open Area (%)	Weigh Per 100 sq' based on 304ss	Opening (Micron)
Plain	2 x 2	.080	.4200	70.6	83	10687
Plain	2 x 2	.063	.4370	76.4	51.7	11119
Plain	2 x 2	.054	.4460	79.6	37.6	11348
Plain	3 x 3	.0800	.2530	57.6	126.4	6438
Plain	3 x 3	.0720	.2610	61.3	101.9	6641
Plain	3 x 3	.0630	.2700	65.6	77.6	6870
Plain	3 x 3	.0540	.2790	70.1	57.3	7099
Plain	3 x 3	.0470	.2860	73.6	42.8	7277
Plain	3 x 3	.0410	.2923	76.7	32.5	7438
Plain	4 x 4	.1200	.1300	27.0	392.5	3308
Plain	4 x 4	.1050	.1450	33.6	309.3	3690
Plain	4 x 4	.0920	.1580	39.9	233.3	4020
Plain	4 x 4	.0800	.1700	46.2	173.8	4326
Plain	4 x 4	.0720	.0178	50.7	139.6	453
Plain	4 x 4	.0630	.1870	56.0	105.8	4758
Plain	4 x 4	.0540	.1960	61.5	77.2	4987
Plain	4 x 4	.0470	.2030	65.9	58.2	5165
Plain	4 x 4	.0410	.2090	69.9	44	5318
Plain	4 x 4	.0350	.2150	74.0	32	5471
Plain	4 x 4	.0320	.2180	76.0	26.7	5547
Plain	4 x 4	.0280	.2220	78.9	20.4	5649
Plain	4 x 4	.0250	.2250	81.0	16.3	5725
Plain	5 x 5	.0630	.1370	46.9	134.5	3486
Plain	5 x 5	.0540	.1460	53.3	97.7	3715
Plain	5 x 5	.0470	.1530	58.5	73.3	3893
Plain	5 x 5	.0410	.1590	63.2	55.4	4046
Plain	5 x 5	.0350	.1650	68.1	40.2	4198
Plain	5 x 5	.0320	.1680	70.6	33.5	4275
Plain	6 x 6	.0630	.1040	38.9	164.6	2646
Plain	6 x 6	.0540	.1130	46.0	118.9	2875
Plain	6 x 6	.0470	.1200	51.8	89.1	3053
Plain	6 x 6	.0410	.1260	57.2	67.2	3206
Plain	6 x 6	.0350	.1320	62.7	48.6	3359
Plain	6 x 6	.0320	.1350	65.6	20.7	3435
Plain	6 x 6	.0280	.1390	69.6	30.8	3537
Plain	7 x 7	.0350	.1080	57.2	57.1	2748
Plain	7 x 7	.0320	.1110	60.4	47.5	2824
Plain	7 x 7	.0280	.1150	64.8	36.2	2926
Plain	8 X 8	.0630	.062	24.6	218.5	1578
Plain	8 X 8	.0540	.071	32.3	164.3	1807
Plain	8 X 8	.0470	.0780	38.9	122.1	1985
Plain	8 X 8	.0410	.0840	45.2	91.5	2137
Plain	8 X 8	.0350	.0900	51.8	65.1	2290
Plain	8 X 8	.0320	.0930	55.4	54.6	2366
Plain	8 X 8	.0280	.0970	60.2	47.1	2468
Plain	8 X 8	.0250	.1000	64.0	32.9	2545
Plain	9 X 9	.0410	.0700	39.7	104.2	1781
Plain	9 X 9	.0350	.0760	46.8	74.7	1934
Plain	9 X 9	.0320	.0790	50.6	62	2010
Plain	9 X 9	.0280	.0830	55.8	47.1	2112
Plain	9 X 9	.0250	.0860	59.9	37.3	2188
Plain	9 X 9	.0230	.0880	62.7	31.4	2239
Plain	10 x 10	.0470	.0530	28.1	149.9	1349
Plain	10 x 10	.0410	.0590	34.8	117.5	1501
Plain	10 x 10	.0350	.0650	42.3	83.9	1654
Plain	10 x 10	.0320	.0680	46.2	69.5	1730
Plain	10 x 10	.0280	.0720	51.8	52.6	1832
Plain	10 x 10	.0250	.0750	56.3	41.6	1908
Plain	10 x 10	.0230	.0770	59.3	35.1	1959
Plain	10 x 10	.0200	.0800	64.0	26.4	2036
Plain	11 x 11	.0320	.0590	42.1	77.2	1501
Plain	11 x 11	.0280	.0630	48.0	58.4	1603
Plain	11 x 11	.0250	.0660	52.7	46.1	1679
Plain	11 x 11	.0230	.0680	56.0	38.8	1730
Plain	11 x 11	.0200	.0710	61.0	29.1	1807
Plain	11 x 11	.0180	.0730	64.5	23.5	1857
Plain	12 x 12	.0320	.0510	37.5	85.1	1298
Plain	12 x 12	.0280	.0550	43.6	64.1	1399
Plain	12 x 12	.0250	.0580	48.4	50.6	1476
Plain	12 x 12	.0230	.0600	51.8	42.6	1527
Plain	12 x 12	.0200	.0630	57.2	31.9	1603
Plain	12 x 12	.0180	.0650	60.8	25.8	1654
Plain	14 x 14	.0280	.0430	36.2	76.3	1094
Plain	14 x 14	.0250	.0460	41.5	59.9	1170
Plain	14 x 14	.0230	.0480	45.2	50.3	1221
Plain	14 x 14	.0200	.0510	51.0	37.6	1298
Plain	14 x 14	.0180	.0530	55.1	37.6	1349
Plain	14 x 14	.0170	.0540	57.2	26.9	1374
Plain	14 x 14	.0090	.0620	76.4	9	1578
Plain	16 x 16	.0280	.0345	30.5	84.4	878
Plain	16 x 16	.0250	.0375	36.0	69.6	954
Plain	16 x 16	.0230	.0395	39.9	58.3	1005
Plain	16 x 16	.0200	.0425	46.2	43.4	1081
Plain	16 x 16	.0180	.0445	50.7	34.8	1132
Plain	16 x 16	.0160	.0465	55.4	27.4	1183
Plain	16 x 16	.0090	.0535	73.3	8.6	1361
Plain	18 x 18	.0250	.0306	30.3	75.8	779
Plain	18 x 18	.0230	.0326	34.4	66.7	830
Plain	18 x 18	.0200	.0356	41.1	49.5	906
Plain	18 x 18	.0180	.0376	45.8	39.6	957
Plain	18 x 18	.0170	.0386	48.3	35.1	982
Plain	18 x 18	.0160	.0396	50.8	31	1008
Plain	18 x 18	.0150	.0406	53.4	27.1	1033
Plain	18 x 18	.0140	.0416	56.1	23.5	1059
Plain	18 x 18	.0135	.0421	57.4	21.8	1071
Plain	18 x 18	.0090	.0466	70.2	9.6	1186
Plain	20 x 20	.0280	.0220	19.4	110.4	560
Plain	20 x 20	.0250	.0250	25.0	85.9	636
Plain	20 x 20	.0230	.0270	29.2	71.5	687
