Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Specifications
Certification :
CE
MOQ :
1
Price :
500
Model NO. :
MF-DS
Opening Type :
Power Driven
Operating Temperature :
-30°C to 70°C
Thickness :
3.0 mm
Width :
3400/3600(mm)
Height :
3400/3800(mm)
Top airbag elongation :
1200(mm)
Side airbag elongation :
800(mm)
Top visor :
500(mm)
Side visor :
250(mm)
Power supply :
380V,50Hz
Power :
0.75Kw
Protection level :
IP54
Airbag inflation time :
25s
Maximum tensile capacity :
>290N/mm2
Description
Cold Storage Warehouse Adjustable Inflatable Loading System Dock Shelter
Mechanical dock shelters are manufactured in accordance with European standards and provide effective sealing between loading/unloading areas and freight vehicles. This ensures quick and safe loading operations in any weather conditions, making it an ideal solution for medium-strength loading sites.
Key Features
  • Fits vehicles of any size from small trucks to standard trucks
  • Excellent sealing function prevents wind and foreign matter entry
  • Hot-dip galvanized steel arc construction with 60 x 30 mm cross-section
  • Polyester PVC self-extinguishing textile (750 g/m³) with reinforced points
  • Weather-resistant operation from -35°C to +70°C
Technical Specifications
Width 3400/3600 (mm)
Height 3400/3800 (mm)
Top Airbag Elongation 1200 (mm)
Side Airbag Elongation 800 (mm)
Top Visor 500 (mm)
Side Visor 250 (mm)
Profile Color Aluminum Color
Door Color White
Control Method Switch/Platform Control Unit
Power Supply 380V, 50Hz
Power 0.75Kw
Control Unit External
Protection Level IP54
Airbag Inflation Time 25s
Operating Temperature -35°C to +70°C
PVC Curtain Board Weight 3.6kg/m
PVC Thickness 3mm
Airbag Material Cordura 1000
Airbag Thickness 0.5mm
Airbag Weight 0.4kg/m
Maximum Tensile Capacity >290N/mm²
Foam Board Thickness 50mm
Internal/External Color White
Product Images
Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation Cold Storage Warehouse Adjustable Inflatable Loading Dock Shelter with Sealing and Insulation
Frequently Asked Questions
What is the minimum order quantity for the product?
There is no minimum order quantity for our products. We recommend using wooden crates for protection during shipping.
Sizes and application scenarios of various products in our factory?
We provide customers with professional suggestions and drawings based on their needs to deliver the best solutions.
Can I get industrial door samples for quality checking?
Yes, samples are available for quality verification.
How do I get a price for the product I need?
Please provide the exact size and quantity requirements. We will provide a detailed quotation plan according to your specifications.
What payment terms will you accept?
We typically accept T/T (Telegraphic Transfer) payments.
We would like to be your agent in our area. How to apply for this?
We welcome partnership opportunities. Please send your ideas, company or personal information via email to discuss collaboration.
Can you send me the price list?
Yes, since products are customized to your requirements, we can provide quotations for regular sizes upon request.
Is it convenient to visit your factory?
Yes, our factory is conveniently located only 2.5 hours drive from Shanghai Airport. You are welcome to visit our facility and experience local hospitality.
