Electro - Hydraulic 100kg/H Dry Granulator Equipment
Electro - Hydraulic 100kg/H Dry Granulator Equipment
Electro - Hydraulic 100kg/H Dry Granulator Equipment
Electro - Hydraulic 100kg/H Dry Granulator Equipment
Specifications
Brand Name :
YIGAN
Model Number :
GK
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Supply Ability :
10 sets per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Packed in film firstly, and then reinforced with wooden case for outer packing
Product Name :
Dry granulator machine/dry granulator equipment
Application :
pressed pill
Granules shape :
Pieces shape
Feature :
electric hydraulic
Process object :
Dry powder
Standard :
CE/ROHS/FCC/SGS
Description

New Type Electric Hydraulic Dry Granulator Equipment for pressed pill

Main Application

New Type Electric Hydraulic Dry Granulator Equipment for pressed pill makes raw material from powder to granule directly.

The granules produced by the equipment could press tablet, be infusion and fill in capsule. The machine is suitable in pharmaceutical industry, food industry, chemical industry and so on, specially suit for the material couldn’t granulating by wet process.

Features

1. Density of dry powder-granule is uniform, solubility is good.

2. Special raw material transmission construction system could keep efficient working.

3. Roller water is in circular cooling, raw material won’t stick to roller.

4. There’s no need for wetting agent such as water or ethanol, no need for second heating drying, less working procedure, high efficiency and low cost.

5. It is adapted Electro-hydraulic, easy in operation.

6. Closed operation could meet the requirement of GMP.

Working Principle

Powder material after mixing,sent to the feeding bin from granulator' top feeding mouth,mixed powder materials is pushed down by screw feeding mechanism,Powder drops into the gap between the two rollers,The roller is rotating and the powder is pressed into slices by cylinder,slices drop down and be granulated by granulator to the particles that needed.

Technical Parameters

Type GK-80 GK-120
Production capacity(kg/h) 20-60 30-100
Fineness of granules(mm) 0.3-1.5 0.3-1.5
Power(KW) 7.15 14
Working pressure(KN) 198 198
Overall dimensions (L*W*H)(mm) 1540*1230*2325 1980*1500*2580
Weight(kg) 2300 3500
