Insulated High Temperature And High Voltage Wire

200°C Teflon Insulated Wire UL1330/1332/1333

1. Rated: 200°C 300V/600V;

2. Conductor uses single or multiple stranded wires of tin-plated copper or bare copper;

3. Insulation uses FEP or ETFE Teflon plastic, available in red, blue, yellow, green, black, orange, and transparent;

4. Excellent electrical performance, high voltage resistance, low high-frequency loss, non-hygroscopic, and high insulation resistance;

5. Excellent heat resistance, flame retardancy, aging resistance, oil resistance, solvent resistance, and acid and alkali resistance.

250°C Teflon Insulated High-Temperature Wire UL1911/10362

1. Rated: UL1911 250°C 30KV, 25KV, 20KV, 15KV, 10KV; UL10362 250°C 600V

2. Conductor uses single or multiple stranded wires of tin-plated copper, nickel-plated copper, silver-plated copper, or bare copper;

3. Insulation uses PFA (MFA) or PTFE Teflon plastic, available in red, blue, yellow, green, black, orange, and transparent;
4. Excellent electrical performance, high voltage resistance, low high-frequency loss, non-hygroscopic, and high insulation resistance;

5. Excellent heat resistance, flame retardancy, aging resistance, oil resistance, solvent resistance, and acid and alkali resistance.

Teflon-insulated high-voltage, high-temperature resistant wire UL3239

1. Rated: 200℃, 30KV, 25KV, 20KV, 15KV, 10KV;

2. Conductor uses tin-plated copper or bare copper single or multiple stranded wires;

3. Insulation uses FEP or PTFE Teflon plastic, semi-transparent or white in color; sheath uses FEP, available in red, blue, yellow, green, black, orange, transparent, etc.;

4. Excellent electrical performance, high voltage resistance, low high-frequency loss, non-hygroscopic, high insulation resistance;

5. Excellent heat resistance, flame retardancy, aging resistance, oil resistance, solvent resistance, and acid and alkali resistance. Silicone Rubber

Insulated High Temperature and High Voltage Wire UL3573

1. Rated: 200℃ 10KV;

2. Conductor uses tin-plated, nickel-plated copper, or bare copper single or multiple stranded wires;

3. Insulation uses silicone rubber, surface colors include white, red, yellow, blue, brown, black, and green;

4. Excellent electrical performance, good heat resistance and aging resistance.
