Pressure Atomization Vacuum Cone Dryer 5000L Rotocone Vacuum Dryer
Pressure Atomization Vacuum Cone Dryer 5000L Rotocone Vacuum Dryer
Specifications
Supply Ability :
50L to 5000L
Payment Terms :
L/C, T/T
Model NO. :
SZG
Type of Atomization :
Pressure Atomization
Sprayer :
Pressure-Type
Appearance of Dried Sample :
Powder, Granule, Bulk
Type of Flow :
Vacuum
Trademark :
Changzhou Fanqun
Transport Package :
Foam
Specification :
CE
Origin :
Changzhou, China
HS Code :
84199090
Port :
Shanghai, China
Movement Way :
Combined
Heating Mode :
Steam, Hot Water
Drying Medium :
Steam, Hot Water
Operational Method :
Intermittent
Structure :
Air Flow Drier
Operation Pressure :
Vacuum Dryer
Description

Special Cone Dryer for Drying Plastics

Product Description

Customer Question & Answer

Ask something for more details
About SZG Cone Dryer

SZG cone dryer is a kind of rotary cone tank dryer which dries product in a vacuum status. Steam or hot water could be put into the jacke and product contact with the hot internal wall and be dried.


Advantage of Cone Dryer

- High heating efficiency
- Easy operation
- Easy cleaning
- Energy saving
- Options with condenser / without condenser


Applications:

- Suitable for drying heat sensitive products with low temperature.
- Suitable for drying easy oxidized products.
- Suitable for drying sterilizing and antipollution pharmaceutical products.
- It can be used to re-dry products with low moisture
- Catalyst
- Aluminum hydroxide
- Chemical product
- Dyes
- Food

Flow Chart
Pressure Atomization Vacuum Cone Dryer 5000L Rotocone Vacuum Dryer


Technical Parameter
Model Volume
(L)		 Heat Area
(m2)		 Motor Power
(Kw)		 Overall Dimension
(mm)		 Weight of main machine (kg)
SZG-1000 1000 5.1 3 2858x1300x2830 2800
SZG-1500 1500 6.5 4 3062x1300x2940 3300
SZG-2000 2000 8.2 5.5 3262x1400x2990 3580
SZG-3000 3000 10.2 7.5 3762x1800x3494 5950
SZG-5000 5000 18.2 15 4280x2490x3730 9960


Note: customermized design is available.
