U Beam Structure 50kg Accuracy 120T Mine Truck Weighing Scales
U Beam Structure 50kg Accuracy 120T Mine Truck Weighing Scales
U Beam Structure 50kg Accuracy 120T Mine Truck Weighing Scales
U Beam Structure 50kg Accuracy 120T Mine Truck Weighing Scales
Specifications
Brand Name :
Purple Horn
Model Number :
SCS-60T
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
1 set
Price :
Negotiated price
Payment Terms :
L/C, T/T
Supply Ability :
2000+ set per year
Delivery Time :
15~25days
Packaging Details :
20GP or 40GP container (the platform of truck scale is nude packed and the accessories are packed in carton or wooden box)
Name :
50T weighbridge
Structure :
U-beam
Capacity :
60T to 120T
Accuracy :
20kg or 50kg
Size :
3x15m or custom
Load cells :
Digital
Safe overload :
150%FS
Ultimate overlad :
300%FS
Indicator :
LED display
Power :
110V+-10%; 220V +-10% AC, 50 or 60Hz
Place Of Origin :
CHINA
Description

U-Beam Structure 50kg Accuracy 120 Ton Weighing Scales For Mine Trucks

Truck scale introduction:

  1. Plate: 8-20mm Q235 steel plate with coating painting /6-8 Pcs U beam design
  2. Sensor: KELI or Zemic with OIML certificate sensor
  3. Junction box: YAOHUA or KELI waterproof junction box
  4. U beam thickness design with 6mm
  5. Pre camber machine to making platform have a high curve in Middle of platform
  6. Auto welding machine to ensure welding is smooth and good strength
  7. Shot blasting clean all dirty before painting

SCS Truck scale platform size:

Model Platform Size(width*length)(m) Capacity(T) Division(kg)
SCS-10 3*8 10 5
SCS-20 3*8 20 10
SCS-30 3*8 3*10 30 10
SCS-40 3*8 3*10 3*12 3*14 40 10
SCS-50 3*10 3*12 3*14 3*16 50 10
SCS-60 3*10 3*12 3*14 3*16 60 10
SCS-80 3*12 3*14 3*16 3*18 3*21 80 10
SCS-100 3*14 3*16 3*18 3*21 100 20
SCS-150 3*18 3*21 120 20
