Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer
Specifications
Brand Name :
Purple Horn
Model Number :
SCS-60T
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD5000~14500
Payment Terms :
L/C, T/T
Supply Ability :
100 Set/Sets per Month
Delivery Time :
10~25 days
Packaging Details :
The body of truck weight bridge is nude packed and the accessories are packed in cartons
Material :
Q235
Load cell :
Digital
Power supply :
220V AC or 9V DC
Accuracy :
OIML 3
Safe overload :
150%
Structure :
U-shape Beams
Interface :
RS232C / Printer / PC
Warranty :
1 Year
Place Of Origin :
CHINA
Description

Modular Design 60 Ton Electronic Truck Scale Weighbridge With Printer

The SCS Truck scale (weighbridge) is available in both surface and pit mount designs. Key features include:

  • Low profile deck design – only 300 mm high
  • Driver-operated versions
  • Guide rails standard on surface models
  • Optional steel ramps, bar, and anti-skid design
  • Modular construction
  • Non-standard widths & lengths up to 150 Tons
  • Special paint
  • Multi-range – high accuracy versions
  • Wide range of weighbridge peripherals

Truck Scale Technical Paramater
Type Digital truck scale
Platfrom size From 6m to 24m
Platform material 8-20mm thickness top steel plate
Painting poxy zinc rich primer and acrylic marine paint
Max. Cap From 30ton to 150ton available
Accuracy 10kg, 20kg, 50kg (OIML Ⅲ)
Safe over loade 150%F.S
Power supply 110V+-10%; 220V +-10% AC or DC, 50 or 60Hz
Load cell Keli digital load cell or ZEMIC digital load cell
Weighing indicator YAOHUA or Purple Horn indicator
Interface RS232 (or RS485), PC, printer, extra scoreboard
Working temperture -10~40ºC(indicator), -30~75ºC(load cell)
Working humidity ≤95%
Certificate CE, OIML, ISO9001:2015
Warranty 12 months

Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer

Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer

Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer

Modular Design 60 Ton Truck Weight Scale , Weighbridge Truck Scale With Printer

Recommended dimension for Purple Horn truck scale platform
Capacity(Tons) 30 40 50 60 80 100 120 150
Division Value 5KG/10KG/20KG/50KG
Platform size:L*W(m) Recommended size Packing(container)
3*7 √ √ 1x20'GP
3*9 √ √ √ √ √ 1x20'GP
3*12 √ √ √ √ √ √ 1x20'GP
3*14 √ √ √ √ √ √ 1x20'GP
3*16 √ √ √ √ √ 1x20'GP
3*18 √ √ √ √ √ 1x20'GP
3*20 √ √ √ √ 1x40'GP
3*22 √ √ √ 1x40'GP
3*24 √ √ 1x40'GP
Remark Other capacity, size and apprearance can be customized according your requirements.
