SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
Specifications
Brand Name :
KEDA
Model Number :
SCS-50T
Certification :
ISO9001:2018
Place of Origin :
Guangdong, China
MOQ :
1 set
Price :
Negi
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per month
Delivery Time :
10~25 days
Packaging Details :
The platform of weighbridge is nude packed and other electronic accessories is packed by carton box or wooden case.
Product name :
Weighbridge
Model :
SCS-50
Platform size :
Custom
Material :
Q235 Steel
Capacity :
50 Ton
Accuracy :
5/10kg
Accuracy Class :
OIML 3
Warranty :
12 months
Description

5/10KG Accuracy 50 Ton Electronic Digital Dynamic Weighbridge

Truck scale introduction:

 Truck scale (weighbridge) platform, high accuracy weighing load cells, weight indicator, junction box and shield cable are necessary parts of a basic truck scale (weighbridge). Printer, scoreboard and computer management system are optional so as to complete the requirements of data management and transmission on the higher level.
Plate Material Q235 carbon steel, 8/10/12mm steel plate is optional
Indicator/Display Analog A9, A9P optional(OIML&CE approved), Digital Yaohua DS10 or DS8 and Keli D2008H
Load Cells Keli or Zemic bridge type digital load cells
Display Designators On/Off, Zero, Tare, kg/lb.
Transmission Distance RS232C≤30m
Power Supply Rechargeable Battery, AC 220V;50Hz (-2%~+2%), DC 12V/7AH
Junction box Anti-surge junction box, 4, 6,8,10,12-wire are optional, adapt to all weighing systems
Signal cable 20m single shielded 4-core cable, can't cut when use otherwise will effect accurate
Color Standard color

Recommended dimension for KEDA truck scale platform
Capacity(Tons) 30 40 50 60 80 100 120 150
Division Value 5KG/10KG/20KG/50KG
Platform size:L*W(m) Recommended size Packing(container)
3*7 √ √ 1x20'GP
3*9 √ √ √ √ √ 1x20'GP
3*12 √ √ √ √ √ √ 1x20'GP
3*14 √ √ √ √ √ √ 1x20'GP
3*16 √ √ √ √ √ 1x20'GP
3*18 √ √ √ √ √ 1x20'GP
3*20 √ √ √ √ 1x40'GP
3*22 √ √ √ 1x40'GP
3*24 √ √ 1x40'GP
Remark Other capacity, size and apprearance can be customized according your requirements.
