SIP2.0 SS Vandal Resistant Telephone IP54 VoIP Desk Mounting
SIP2.0 SS Vandal Resistant Telephone IP54 VoIP Desk Mounting
SIP2.0 SS Vandal Resistant Telephone IP54 VoIP Desk Mounting
SIP2.0 SS Vandal Resistant Telephone IP54 VoIP Desk Mounting
Specifications
Brand Name :
J&R
Model Number :
JR211-FK
Certification :
CE, FCC, RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 Piece
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union,PayPal
Supply Ability :
10000pcs per month
Delivery Time :
3-7 working days after payment
Packaging Details :
J&R standard packing ,pearl cotton, carton
Size :
300 *150 *160(mm)
Color :
Gray or Customized
Material :
Die Cast Aluminum
Function :
Communication
Installation :
Desk mounting
Ringer volume :
90~95dB(A) at a distance of 1 m
Temperature :
Operating: -30°C to +65°C
Ingress Protection Rating :
IP54-IP65
Warranty :
2 Years
Net Weight :
3 kg
Gross Weight :
4 kg
Description

JR211-FK IP65 VoIP Stainless Steel Vandal Resistant Telephone

JR211-FK VoIP Stainless Steel Desk Telephone supports the hotline call, may realize the call to hang up automatically, which is suitable for tunnel, railway, underground mine, prison, guard room, bank and many other areas.

The shell of JR211-FK has a grounding device and is completely isolated from the internal electrical circuit, which has a certain electromagnetic shielding function.

The main circuit of the telephone is controlled by industrial grade atml single chip microcomputer, while the performance is stable, the intelligence degree is high, and the program can be upgraded.

IP65 VoIP Stainless Steel Vandal Resistant Telephone Technical Specification

Analogue Version
Power Supply From the analogue telephone network
Supply Voltage 24VDC to 65 VDC
Supply Current 20 mA DC to 100 mA DC
Ringer Volume - 80dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method DTMF mode in accordance with ITU-T recommendation Q.23.

SIP Version
Power Supply PoE or 12V DC
Power Consumption -Idle:1.5W
-Active:1.8W
SIP Protocol SIP 2.0 (RFC3261)
Support Codec G.711 A/U, G.722 8000/16000, G.723, G.729
Communication Type Full duplex
Ringer Volume - 90~95dB(A) at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)

Ambient conditions
Protection Type IP 66 as per EN60529
Operating Temperature -30°C to +70°C
Storage Temperature -40°C to +75°C

IP65 VoIP Stainless Steel Vandal Resistant Telephone Features

★ Compatible W/PBX, Centrex, etc
★ Constructed of durable 14 gauge stainless steel

★ Armored handset desk phone with reinforced armored cord

★ Internal lanyard inside the armored cord sheath
★ Metal Magnetic cradle hook for extra protection

★ Built in ringer can be left on or turned off

IP65 VoIP Stainless Steel Vandal Resistant Telephone Applications

JR211-FK VoIP Stainless Steel Desk Telephone is suitable for the centre of transport, production production and utilities commercial, manufacturing and construction, educational & government facilities or any location in which extra security is needed.

IP65 VoIP Stainless Steel Vandal Resistant Telephone Packing & Delivery

Unit Size 300 *150 *160 (mm)
Carton Size 200 *300 *440 (mm)
Packaging Materials Pearl cotton, carton
Net Weight 3 KG
Gross Weight 4 KG

IP65 VoIP Stainless Steel Vandal Resistant Telephone Customised Accessories

  • J&R provide LOGO printing and accessories customization services.
  • We will also provide suitable solutions according to the needs of customers.
  • HOOK FUNCTION: Magnetic hooks for choice
  • KEYBOARD SHAPE: Round buttons and square buttons for choice
  • INDICATOR LAMP COLOR: Red, yellow, blue, green for choice
  • MOTHERBOARD MODEL: 2G/3G/4G/SIP/GSM for choice
  • HADSET CORD: Black curly handset cord or stainless steel spiral cord​
  • If you have any custom requirements, please feel free to contact us.

FAQ

IP65 VoIP Stainless Steel Vandal Resistant Telephone

Q: Do you have any MOQ limit?

A: Low MOQ, 1pc is available

Q: Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q: What’s the quality standard of your products?

A: CE, FCC, RoHS, ISO9001:2015 certification approved. All materials are in high grade and new. With the strict quality,every phone be thoroughly tested before leaving the factory.

Q: Is it OK to print my logo on the products?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q: Can you produce a product in a color of my choosing?

A: Yes, we can manufacture products in different colors, however there may be minimum quantities or surcharges applicable.

Q: Do you provide an installation service?

A: No, we do not install products, but they are very straightforward to install, please kindly contact us if unsure.

Q: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products against delivery.

Q: How about the shipping?

A: 1.Send by DHL / TNT / UPS / FEDEX / EMS,3-5days

2.Send by Air: Arrive at destination Airport fast then pick it up by yourself

3.Ship by Sea: Low shipping cost and slow delivery (15 - 30 days)

Q: How can I pay you?

A: Many convenient methods for choose: Paypal, T/T, L/C.
