Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Endress Hauser Cerabar M Pmp 41 Stainless Pressure Transmitter
Specifications
Brand Name :
E+H
Model Number :
PMP41
Place of Origin :
China
MOQ :
1 pc
Price :
USD 300 1 pc
Payment Terms :
T/T
Supply Ability :
100 pc 1 week
Delivery Time :
7-14 days
Hart Protocol :
Available
Overpressure Limit :
2 times the maximum range
Pressure Type :
Gauge Pressure
Range :
0-10,000 psi
Communication Protocol :
HART
Certifications :
CE, ATEX, FM, CSA
Accuracy :
±0.2% of span
Output Signal :
4-20 mA
Mounting :
Direct or remote
Customized Support :
OEM, ODM, OBM
Mounting Type :
Threaded
Warranty :
12 months
Long Term Stability :
±0.2% of URL for 5 years
Material :
Stainless steel
Vacuum Resistance :
10 mbar (0.15 psi)
Description

Endress Hauser Cerabar M PMP 41 Stainless Pressure Transmitter



Applications

The Cerabar M transmitters measure the gauge and absolute pressure of gases, vapours, liquids and dusts and can be used in all areas of process engineering. The modular design of the Cerabar M enables it to be used in all industrial environments.

Features and Benefits

• Accuracy

− Linearity better than 0.2% of set span

− Adjustable measuring range with TD 10:1

− Long-term stability better than 0.1%

• Sensors

− Dry capacitive ceramic sensor up to 40 bar (600 psi)

– corrosion and abrasion resistant with high overload protection and vacuum-tightness − Piezoresistive metal sensor for measuring ranges up to 400 bar (6000 psi)

• Electronics

− Analogue: low-cost and accurate with short response time especially for rapid processes

− Smart: intelligent with versatile operating procedures via HART protocol

− PROFIBUS-PA: tried and tested for digital communications

• Housings

With its stainless steel housing without dead volume, the Cerabar M fulfils all the special hygienic requirements of the food and pharmaceutical industries. The polyester-epoxy coated aluminium housing has been field-proven in the process industry.

• Process connections

All customary thread versions, hygienic connections and flanges are available.


item
value
place of origin
original
warranty
1 Year
customized support
OEM, ODM
brand name
E+H
material
Stainless steel and aluminum
color
/
power
/
