Lenze MCS 19J30-SRSB0 synchronous servo motors
Lenze MCS 19J30-SRSB0 synchronous servo motors
Specifications
Delivery Time :
5-8days
Price :
Negotiation
Programminglanguage :
Ladder Logic, Structured Text
Place of Origin :
china
Brand Name :
Lenze
Responsetime :
Milliseconds to Seconds
Payment Terms :
T/T
Application :
Pumps, conveyors, compressors, fans
Model Number :
MCS 19J30-SRSB0
Packaging Details :
pieces
Userinterface :
HMI Touchscreen / Remote Monitoring
MOQ :
1
Powerrating :
0.5 kW to 500 kW
Material :
Cast iron / Aluminum housing
Description

Lenze MCS 19J30-SRSB0 Permanent Magnet Synchronous Servo Motor (ECER Standard | English Only)

Lenze MCS19 Servo Motor
MCS19J30 Outline
MCS Series Servo Motor

1. Product Overview

MCS 19J30-SRSB0 is high-performance permanent magnet synchronous servo motor under German Lenze L-force MCS product platform, engineered for high-dynamic precision closed-loop motion control, matched with Lenze i700 / i950 series servo drivesLenze. Adopting proprietary SEPT single-element pole winding & high-energy rare-earth magnet design, it features ultra-high power density and low rotor inertia, widely matched with Lenze G500/G7X0/G8X0 precision gear reducers for integrated geared servo drive solutions. SRSB0 configuration stands for resolver feedback + plug-type quick connector + holding brake + natural cooling structure, complying with EU ECER machinery safety & EMC industrial standards.

2. Core Advantages & Key Features

  • SEPT Optimized Winding Technology: Independent single-coil stator structure boosts power density by 18%, lower cogging torque for ultra-smooth low-speed running, full-load efficiency ≥93%.
  • Superior Dynamic Performance: Low inertia rotor design enables 3x rated peak overload within 3s, rapid angular acceleration response for high-speed start-stop & positioning action.
  • Standard Resolver Feedback (SRSB0 Spec): Robust resolver position feedback, strong anti-vibration & anti-interference, reliable for dusty/humid harsh workshop environment; optional incremental/absolute OCT single-cable encoder upgrade.
  • Plug-in Quick Connect Wiring: SpeedTec integrated power & feedback plug terminals, no terminal box wiring, shorten on-site installation & maintenance downtime drastically.
  • Built-in Electromagnetic Holding Brake: Integrated spring-applied brake for vertical axis anti-drop during power-off, safe for lifting & rotary positioning equipment.
  • High Ingress Protection: Main body IP65 protection (natural cooling type), dustproof & splash-proof for cabinet-mounted & partial open-machine installation; forced cooling variant IP54.
  • Electronic Nameplate Function: Pre-stored motor parameter inside, auto parameter identification with Lenze servo drive for fast commissioning without manual parameter entry.
  • Full global certification: CE, UL, RoHS compliant, fully conform to EN60034, EN61800, ECER industrial specification for EU export clearance.

3. Detailed Technical Specification Table

表格



Item Technical Parameter
Brand Lenze (Made in Germany)
Model MCS 19J30-SRSB0
Motor Type Permanent Magnet Synchronous Servo Motor
Rated Power 9.1kW / 12.2HP
Rated Torque 29 N·m Peak Torque: 87 N·m (3s overload)
Rated Speed 3000 rpm, Max speed: 4500 rpm
Rated Input Current 18.5A, DC bus supply 300V (matched with 400V class servo drive)
Feedback Configuration Resolver (SRS standard spec)
Shaft Spec Φ28×60mm with keyway (IEC standard B5 flange mounting)
Cooling Method Natural convection self-cooled
Accessory Built-in electromagnetic power-off holding brake
Protection Grade IP65
Ambient Operating 0~40℃, RH 5~90% non-condensing, non-corrosive gas environment
Compatible Drive Lenze i700, i950 cabinet servo invertersLenze
Mounting Standard IEC B5 flange surface mounting

4. Application Industry & Warehouse Info

Main Application Fields

  1. High-speed Packaging Equipment: Carton forming, labeling, cutting & filling axis precise control
  2. Printing & Paper Processing: Register control of rotary printing machine, slitter winding positioning
  3. Automated Industrial Robot: Multi-joint rotary & linear actuator drive
  4. CNC Automation: Special machine tool spindle & feed axis servo control
  5. Material Handling & Logistics: Automated palletizer, high-speed sorting conveyor drive
  6. Textile Machinery: Spinning & weaving high-speed loom motion control

Warehouse Storage Standard

Original German export carton with inner shockproof foam packaging, fixed on moisture-proof plastic pallet in constant-temperature dry warehouse away from corrosive chemicals. All units pass factory full-load aging test before delivery, spot stock & bulk OEM order available.
