Schneider XCE102C Steel Roller Plunger Horizontal Actuation Limit Switch 1NO 1NC IP65 Spring Return Industrial Travel Switch
Schneider XCE102C Steel Roller Plunger Horizontal Actuation Limit Switch 1NO 1NC IP65 Spring Return Industrial Travel Switch
Specifications
Delivery Time :
5-7 days
Brand Name :
Schneider
MOQ :
1 pcs
Application :
Position detection, safety interlock
Operatingforce :
0.5N to 5N
Payment Terms :
T/T
Mechanical Life :
1,000,000 cycles
Supply Ability :
10000 pcs
Ip Grand :
IP68
Model Number :
XCE102C
Price :
Negotiation
Ip Protaction :
IP65
Description

Schneider XCE102C Steel Roller Plunger Limit Switch

Product Overview

Schneider XCE102C (OsiSense XC Series) is a horizontal‑actuated steel roller plunger limit switch for industrial travel and position control. It features a spring‑return mechanism, 1NO+1NC contacts, and IP65 protection. Designed for medium‑duty automation, it delivers precise, reliable end‑of‑travel stopping, positioning, and safety interlocking in linear motion systems.

Core Advantages

  • Horizontal Steel Roller Plunger: Stainless steel roller for smooth, low‑wear linear actuation from the side.
  • Spring Return: Automatically resets when contact is lost, enabling repetitive cyclic operation.
  • 1NO + 1NC Contact: Combined normally open/closed for flexible circuit design and safety redundancy.
  • IP65 Protection: Dust‑tight and splash‑proof for harsh workshop environments.
  • Snap‑Action Switching: Fast, precise response; 120 cycles/min max operating rate.
  • Durable Construction: Metal‑alloy housing + steel actuator; withstands vibration and impact.
  • Easy Installation & Wiring: Surface‑mount; screw terminals for 6–9 mm cables.

Technical Specifications

Parameter Details
Brand Schneider Electric (Telemecanique Sensors)
Model XCE102C
Series OsiSense XC (Basic)
Type Steel Roller Plunger Limit Switch
Actuator Stainless steel roller plunger, horizontal (side) actuation
Contact 1NO + 1NC (SPST‑NO + SPST‑NC)
Protection Class IP65 (IEC 60529)
Operation Horizontal (uni‑directional), spring return
Actuation Force Max 9 N; Min release 1.5 N
Electrical Rating AC: 3 A / 250 V; DC: 0.3 A / 220 V
Mechanical Life 10,000,000 cycles
Electrical Life 800,000 cycles (AC, 3 A, 220 V)
Operating Rate Max 120 cycles/min
Connection Screw‑clamp terminals (1 × 1.5 mm²)
Cable Entry Gland for Ø6–9 mm cables
Operating Temperature ‑25 °C to +70 °C
Vibration Resistance ±3 mm (10–55 Hz, IEC 60068‑2‑6)
Impact Resistance 30 gn for 11 ms (IEC 60068‑2‑27)
Material Metal‑alloy housing + steel roller/plunger
Dimensions 49 mm × 31 mm × 132 mm
Weight Approx. 0.145 kg
Certifications CE, RoHS, CCC

Application Industries & Scenarios

Main Application Fields

  1. Machine Tools: CNC machines, lathes, milling machines for linear travel limit and tool positioning.
  2. Conveying & Logistics: Belt conveyors, sorting lines, AGVs for end‑stop and position control.
  3. Packaging Machinery: Wrappers, cartoners, labeling machines for stroke limiting and synchronization.
  4. Automation Assembly: Robotic cells, assembly lines for part presence and linear motion control.
  5. Material Handling: Cranes, hoists, lifts for safety limit and over‑travel protection.
  6. Textile & Printing: Looms, printing presses for roll tension and edge detection.

Image Reference

  • Application Photos: Mounted on machine slides, conveyor frames, and robotic arms for horizontal linear detection.
  • Warehouse Photos: Standard packaging, labeled stock, and quality inspection in industrial warehouses.
