The MOOG SM2301D belongs to MOOG Animatics Class5 D-style integrated SmartMotor series with standard NEMA23 mounting flange. It is an all-in-one compact servo unit integrating motor body, servo amplifier, motion controller, Hall position feedback circuit and 24VDC electromagnetic holding brake inside single housing, eliminating external separate servo driver, independent controller and extra brake module.

This servo realizes closed-loop speed, torque and positioning control via onboard programmable program, the built-in 24VDC holding brake locks output shaft tightly under power-off status to prevent position slipping; Hall sensor feedback continuously captures rotor real-time position to guarantee stable commutation & precise positioning. Widely used for fixed-point positioning, intermittent reciprocating drive and vertical-axis anti-drop transmission on precision automated equipment.

• ✅ Full Integrated All-in-one Structure
  Motor+Driver+Controller+Hall Feedback+24V Holding Brake 5-in-1 design, greatly reduce cabinet wiring quantity, save installation space and lower wiring failure rate.

• ✅ 24VDC Power-off Holding Brake Configuration
  Built-in electromagnetic brake powered by standard 24VDC, instant shaft locking after power cut, perfect for vertical installation machine to avoid workpiece dropping and axis displacement.

• ✅ High-stability Hall Sensor Feedback System
  Hall effect real-time rotor position detection, anti-electromagnetic interference, reliable low-speed commutation, stable running under frequent start-stop working condition.

• ✅ Onboard Programmable & Multi-communication Interface
  Pre-installed motion programming system, standard RS232/RS485 serial port, optional CANopen fieldbus, support multi-motor linkage via Combitronic technology.

• ✅ NEMA23 Standard Universal Flange
  Standard NEMA23 installation dimension, direct replacement for most old NEMA23 servo/stepper motors on automation equipment, easy equipment upgrade.

• ✅ Onboard Multi-channel TTL I/O Terminal
  7-channel 5V TTL general I/O for limit switch, homing signal and brake logic control, flexible peripheral signal access.

1. Electronic Automation Assembly Equipment
   Precision lock screw machine, PCB micro-cutting equipment, electronic component sorting & feeding axis; vertical mounting axis rely on built-in 24V brake to prevent falling during power outage.

2. Packaging & Labeling Machinery
   Small automatic labeling machine, carton folding device, intermittent indexing drive of filling equipment, frequent start-stop positioning working scene.

3. Laboratory Precision Testing Equipment
   Biochemical test instrument, micro sample moving platform, high-precision adjustable positioning bench, stable low-speed operation supported by Hall feedback.

4. Small CNC & Automation Gantry Equipment
   Mini engraving machine, micro CNC feed axis, compact gantry mobile drive axis, save cabinet layout space with integrated design.
