MOOG SM3420D-OC2 Servo Motor With 27.1 In-lb Continuous Torque 4500 No-load Speed

1. Product Overview

MOOG SM3420D‑OC2 is a NEMA34 frame SmartMotor™ integrated brushless DC servo motor manufactured by Moog Animatics. It consolidates brushless motor, high‑resolution encoder, power amplifier, motion controller and built‑in digital I/O within one compact housing. The OC2 variant provides enhanced circular connector output for harsh‑condition wiring. It delivers 27.1 In‑lb continuous torque and 4500 RPM no‑load speed. It executes closed‑loop position, velocity and torque control without an external separate servo drive, acting as high‑torque motion actuator for heavy‑load industrial automation equipment.

2. Product Advantages

• ✅ Fully‑integrated all‑in‑one design: motor + encoder + amplifier + motion controller + onboard I/O integrated, reduces cabinet wiring quantity and system failure points
• ✅ High continuous torque: 27.1 In‑lb continuous torque, handles heavy mechanical load requirements
• ✅ 4500 RPM high no‑load speed, balances large torque and fast dynamic response
• ✅ OC2 heavy‑duty circular connector version: anti‑vibration, anti‑loosening, stable connection for workshop vibration scenarios
• ✅ High‑precision built‑in optical encoder, supports accurate closed‑loop position & speed feedback
• ✅ Multiple industrial communication: RS‑232, CANopen fieldbus interface, easy connection with PLC, HMI and upper host system
• ✅ On‑board programmable digital I/O channels, local logic execution supported, configurable via SMI programming software
• ✅ Multi‑level built‑in protection: over‑current, over‑temperature, over‑voltage and stall protection for motor and drive circuit
• ✅ Standard NEMA34 mounting flange, mature mechanical installation interface for automation machinery

3. Technical Parameters

4. Application Industries & Scenarios

Main Application Industries

• Heavy‑duty automated assembly equipment
• Packaging & forming machinery
• Material‑handling and conveyor systems
• Robotics & medium‑size manipulator
• Automated Guided Vehicle (AGV / AMR) driving axes
• Test‑and‑measurement high‑load platforms
• CNC auxiliary processing machinery
• Special‑purpose industrial automation equipment

Application Scenario Description

Mounted on mechanical transmission structures, delivers high‑torque accurate positioning, speed regulation and cyclic motion. Suitable for equipment with heavy load and mechanical vibration, the OC2 circular connector ensures stable wiring in workshop environment.
