MOOG SM3430D Coreless Servo Motor 1.27Nm 6000RPM Integrated Smart Motor
MOOG SM3430D Coreless Servo Motor 1.27Nm 6000RPM Integrated Smart Motor
MOOG SM3430D Coreless Servo Motor 1.27Nm 6000RPM Integrated Smart Motor
MOOG SM3430D Coreless Servo Motor 1.27Nm 6000RPM Integrated Smart Motor
Specifications
MOQ :
1 pcs
Model Number :
SM3430D
Hollow Shaft Diameter :
Ø140 mm - Ø340 mm
Motor Type :
coreless motor
Brand Name :
MOOG
Certification :
Brand new original
Payment Terms :
T/T
Supply Ability :
10000 pcs
Delivery Time :
5-7 days
Torque :
1.27 Nm
Price :
Negotiation
Shipping Method :
DHL,UPS,Fedex,TNT,and EMS
Pressure :
Low Pressure
Item Brand :
100% new
Maximum Speed :
6000 RPM
Description
MOOG SM3430D Coreless Integrated Smart Servo Motor,1.27Nm,6000RPM,NEMA34 All-in-one Motion Control Motor

1. Product Overview


The MOOG SM3430D is a high-performance coreless integrated smart servo motor developed by MOOG Animatics, adopting coreless coil structure + all-in-one integrated design, built-in servo motor body, drive amplifier, motion controller and high-precision encoder in a single compact housing.

It serves as a complete independent motion control unit, directly executes positioning, speed and torque closed-loop control without external separate servo driver; mainly used for high-precision automated positioning, intermittent reciprocating drive, high-speed intermittent indexing & precise transmission on automated equipment, perfectly replacing split servo system to simplify machine wiring and cabinet layout.

2. Product Advantages【产品核心优势・图标配套卖点】


✅ Coreless Motor Structure:Zero cogging torque, ultra-smooth low-speed running, fast dynamic response, high torque density vs volumeMoog Inc.

✅ Full Integrated Smart Design:Motor+Drive+Controller+Encoder 4-in-1, save cabinet space, reduce wiring cost & failure points

✅ Stable 1.27Nm Continuous Torque | Max 6000RPM High Speed:Balanced high torque & high rotation speed, fit high-cycle intermittent operation

✅ Multi-Communication & Programmable:Support RS232/RS485, optional CANopen/EtherCAT fieldbus, onboard editable motion program, 7-channel standard TTL I/O

✅ Compact NEMA34 Standard Flange:Universal installation dimension, direct interchange for old Animatics SM series equipment

3. Technical Specification






Item Technical Parameter
Model MOOG SM3430D
Structure Coreless Brushless Integrated Smart Servo
Frame Standard NEMA34
Continuous Torque 1.27 N.m
Max No-load Speed 6000 RPM
Rated Working Voltage DC48V
Rated Continuous Current 10.26A
Rated Power 400W
Single Net Weight ≈2.27kg(5.0LBS)
Protection Grade IP50
Built-in Encoder High-resolution incremental encoder
Communication RS232/RS485 base, optional Fieldbus
Standard I/O 7CH 5V TTL non-isolated I/O
Working Temp -20℃ ~ +85℃
Origin USA MOOG Animatics

4. Application Industry & Scenes


Application Fields


  1. CNC Automation Equipment: Small CNC engraving, micro CNC cutting machine precise feed axis
  2. Packaging Automation: Filling machine, labeling machine, carton forming high-speed indexing drive
  3. Automated Assembly Line: Electronic component assembly, lock screw machine precision positioning
  4. Semiconductor & Testing Equipment: Wafer handling, precision test bench swing & positioning axis
  5. Medical Automation: Medical lab equipment, precision fluid transmission automation devic

Warehouse Stock Image


Warehouse Note: Original surplus stock, factory sealed packing, full test before delivery, 12-month after-sales warranty available.
