Beckhoff EL2008 Digital Input Module
Beckhoff EL2008 Digital Input Module
Specifications
Payment Terms :
T/T
Power Supply Voltage :
AC240-360V.
Delivery Time :
5-7 days
Brand Name :
Beckhoff
Display :
Optional LCD or LED indicators
Supply Ability :
10000 pcs
Responsetime :
Less than 10 ms
MOQ :
1 pcs
Part Type :
Sysmac CPM2A
Model Number :
EL2008
Actual Value :
Negotiabled price
Price :
Negotiable
Productname :
Programmable Logic Controller
Description

I. Core Specifications (Official Parameters)

Parameter Item Value
Brand/Model Beckhoff EL2008
Number of Channels 8-channel digital output
Rated Voltage 24 V DC (-15%/+20%)
Maximum Current per Channel 0.5 A (Short Circuit Protection)
Short Circuit Current Typical < 2 A
Switching Time TON: 60 μs; TOFF: 300 μs
Electrical Isolation 500 V (E-bus / Field Potential)
Load Type Resistive, Inductive, Luminaire Load
Protection Functions Short Circuit Protection, Reverse Polarity Protection
Status Indication 1 LED per Channel
Communication Protocol EtherCAT
Weight Approx. 55 g
Dimensions (W*H*D) 12 mm * 100 mm * 68 mm
Operating Temperature -25 … +60 °C
Protection Rating IP20

II. Functions and Features

  • Electrical Isolation: 500V isolation enhances system safety and interference immunity.
  • Comprehensive Protection: Output short-circuit protection and reverse connection protection reduce the risk of failure.
  • High-Speed ​​Response: Microsecond-level switching time, suitable for high-speed automation scenarios.
  • Simple Wiring: Single-wire connection saves on wiring costs.
  • No Configuration Required: No address/parameter settings required; plug and play.
