IndraControl VEP40 Programmable Logic Controller with 32-bit RISC Processor DIN Rail Mounting and EtherNet/IP Communication
IndraControl VEP40 Programmable Logic Controller with 32-bit RISC Processor DIN Rail Mounting and EtherNet/IP Communication
Specifications
Model Number :
IndraControl L65
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000pcs
Delivery Time :
5-7 days
Description
IndraControl VEP40 Programmable Logic Controller
Advanced 32-bit RISC processor PLC with DIN rail mounting and comprehensive EtherNet/IP communication capabilities for industrial automation applications.
Core Hardware Specifications
Processor Intel Celeron M 1.0 GHz
Memory Configuration 256 MB DRAM + 256 KB RDS (non-volatile data storage) with CF card expansion support
Integrated I/O 8 Digital Inputs + 8 Digital Outputs (24V DC)
Communication Interfaces Standard: 1× PROFIBUS DP (Master/Slave) + 2× Ethernet (10/100M)
Optional: Sercos III, PROFINET IO, EtherNet/IP
Power Requirements 24V DC (19.2–30V DC), ripple ≤±5%
Power Consumption Approximately 15 W
Power Backup No built-in battery; data maintained via RDS + CF card with filter capacitor included
Physical Dimensions & Shipping
Unit Dimensions 176 × 120 × 108 mm (W × H × D)
Packaging Dimensions Approximately 22 × 18 × 12 cm
Volumetric Weight Approximately 0.00475 m³
Shipping Calculation Based on 1.4 kg gross weight + 0.00475 m³ volumetric weight (charged according to actual weight)
Software & Application Environment
Programming System: IndraLogic 2G (based on CoDeSys V3) with integrated PLC + motion control
Supported Languages: Ladder Diagram (LD), Function Block (FBD), Structured Text (ST), SFC, IL
Target Applications:
  • Packaging machinery
  • Machine tools and CNC systems
  • Printing equipment
  • Assembly line automation
  • Injection molding machines
  • Mid-to-high-end motion control scenarios
Certifications & Environmental Ratings
Safety Certifications CE, UL, CSA
Operating Temperature +5°C to +55°C
Protection Rating IP20
Ideal for demanding industrial automation applications requiring reliable performance, comprehensive communication options, and robust motion control capabilities.
