Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel 7 widescreen TFT display HMI panel with touch operation
Specifications
Model Number :
6AV2124-0GC01-0AX0
Place of Origin :
Germany
Payment Terms :
T/T
Supply Ability :
10pcs 1week
Operating_Temperature_Range :
-20°C to 60°C
Dimensions :
90 mm x 100 mm x 75 mm
Power Supply Voltage :
100 – 240VAC.
Brand Name :
Siemens
MOQ :
1pcs
Price :
Negotiable
Delivery Time :
1week
Output Method :
Relay
Input_Voltage :
24 V DC
Part Type :
Sysmac CPM2A
Description
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI Comfort Panel
7" widescreen TFT display HMI panel with touch operation, designed for industrial automation applications with PROFINET and MPI/PROFIBUS DP connectivity.
Product Overview
The SIMATIC HMI Comfort Panel TP700 features a 7" widescreen TFT display with projective capacitive touch supporting multi-touch and glove operation. This active mature spare part operates on Windows CE 6.0 and provides comprehensive HMI functionality for industrial environments.
Display Specifications
Display Type7" widescreen TFT LCD with LED backlight
Resolution800 x 480 pixels (WVGA)
Aspect Ratio16:9
Color Depth16.7 million colors
Brightness350 cd/m² typical
Backlight Lifetime50,000 hours (L50)
Viewing AngleHorizontal: ±70°, Vertical: ±50°
Contrast Ratio1000:1 typical
Processor & Memory
ProcessorARM Cortex-A8 @ 800 MHz
RAM256 MB DDR3
Flash Memory512 MB
User Configuration Memory12 MB
Operating SystemWindows CE 6.0
Communication Interfaces
PROFINET1 x Ethernet port (RJ45), supports TCP/IP, UDP, ISO-on-TCP, PROFINET RT
MPI/PROFIBUS DP1 x 9-pin D-sub connector, supports MPI (187.5 kbps) and PROFIBUS DP (12 Mbps)
USB Interfaces1 x USB 2.0 host port (Type A), 1 x USB 2.0 device port (Mini USB Type B)
SD Card SlotSupports up to 32 GB SDHC cards
Power Supply
Voltage24 V DC (19.2-28.8 V DC)
Current ConsumptionRated: 0.5 A, Inrush: 0.5 A²*s
Power InputTypically 12 W
Connector3-pin screw terminal (L+, M, PE)
Mechanical Specifications
Dimensions (W x H x D)215 x 150 x 54 mm
Mounting Cutout202 x 138 mm
WeightApprox. 1.2 kg
Protection ClassFront: IP65, Rear: IP20
Advanced Features
  • Data logging to SD card or USB storage
  • Recipe management for creation, editing, and transfer
  • Multi-language support (up to 32 languages)
  • Integrated system and communication diagnostics
  • User management with access rights and password protection
  • Configurable display dimming and automatic sleep mode
  • Configuration backup/restore via USB, SD card, or Ethernet
Environmental Specifications
Operating Temperature0°C to 50°C (32°F to 122°F)
Storage Temperature-20°C to 60°C (-4°F to 140°F)
Relative Humidity5% to 95% (non-condensing)
AltitudeUp to 2000 m above sea level
Vibration Resistance5-150 Hz, 0.5 g
Shock Resistance15 g, 11 ms
Certifications & Approvals
  • CE Mark
  • UL 508
  • CSA C22.2 No. 61010-1
  • RoHS Compliance
  • ATEX Certification for hazardous areas
Note: Configured with WinCC Comfort V11 and higher (TIA Portal). Project transfer available via USB, Ethernet, SD card, or MPI/PROFIBUS DP.
