Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module AI 8xU/R/RTD/TC HF SM 531
Specifications
Power Supply Voltage :
100 – 240VAC.
Application :
Oil and Gas Factory
Number_of_Inputs :
16
Brand Name :
Siemens
Model Number :
6ES7531-7PF00-0AB0
Place of Origin :
Germany
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10pcs 1week
Delivery Time :
5-7work day
Number_of_Outputs :
16
Output Method :
Relay
Memory_Size :
50 KB
Manufacturer :
Siemens
Actual Value :
Negotiabled price
Weight :
0.5 KG
Part No :
750-556
Description
Siemens 6ES7531-7PF00-0AB0 SIMATIC S7-1500 Analog Input Module
High-performance 8-channel analog input module for SIMATIC S7-1500 systems, supporting voltage, resistance, RTD, and thermocouple measurements with exceptional accuracy and diagnostic capabilities.
Key Features: 8 individually configurable channels • 16-bit resolution (up to 21-bit for RTD/TC) • 0.1% accuracy • Galvanic isolation • Calibration in RUN mode • Comprehensive diagnostics
Module Specifications
Order Number 6ES7531-7PF00-0AB0
Product Family SM 531 analog input modules
Product Type Analog Input Module (AI)
Number of Channels 8 channels (individually configurable)
Resolution 16 bit standard, up to 21 bit (RTD and TC measurements)
Accuracy 0.1% of span
Input Signal Capabilities
Input Signal Types Voltage, Resistance, RTD, Thermocouple (U/R/RTD/TC)
Voltage Ranges -1V to +1V, -25mV to +25mV, -250mV to +250mV, -50mV to +50mV, -500mV to +500mV, -80mV to +80mV
RTD Types Supported Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000, Cu10, Cu50, and others
Thermocouple Types K, J, T, E, N, R, S, B, C, L, U, and others
Input Resistance 10 MΩ (voltage)
Electrical & Physical Specifications
Power Supply 24 V DC (19.2 V to 28.8 V)
Current Consumption 55 mA (with 24 V DC supply)
Power Loss 1.9 W
Reverse Polarity Protection Yes
Dimensions (L*W*H) 129 mm * 35 mm * 147 mm (5.08 in * 1.38 in * 5.79 in)
Net Weight 0.410 kg (0.904 lb)
Environmental & Compliance
Operating Temperature 0 to 60 °C (horizontal), 0 to 40 °C (vertical)
Storage Temperature -40 to +85 °C
Humidity 5 to 95% (non-condensing)
Vibration Resistance 5 g (10 to 500 Hz)
Shock Resistance 30 g (11 ms)
EMC Compliance EN 61000-6-2, EN 61000-6-4, EN 61326-1
Additional Information
Delivery Contents Infeed element, shield bracket, shield terminal (Front connector ordered separately)
Front Connector 35-pin (screw or push-in type, not included)
Country of Origin Germany
Standard Lead Time 1 Day
