MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
MITSUBISHI Q312B PLC Q Series 12 Slots, Base unit power supply + CPU + 12 I/O slots
Specifications
MOQ :
1
Number_of_Outputs :
10
Part No :
750-466
Payment Terms :
T/T
Model :
S7-1200
Brand Name :
MITSUBISHI
Packaging Details :
pieces
Memory :
50 KB
Power_Consumption :
5 W
Model Number :
Q312B
CPU_Speed :
100 MHz
Place of Origin :
china
Delivery Time :
5-8days
Price :
Negotiable
Description

MITSUBISHI Q312B | PLC Q Series 12-Slot Main Base Unit

1. Product Overview

The Mitsubishi Q312B is a 12-slot main base unit for the MELSEC-Q Series PLC platform, designed to accommodate one power supply module, one CPU module, and 12 I/O/extension modules for building compact, high-performance control systems. It serves as the central backbone for Q Series PLC configurations, enabling seamless integration of power, processing, and I/O layers in a single rack. The unit supports multi-CPU setups and extension rack connections, making it ideal for mid-to-large-scale automation projects requiring flexible I/O expansion and high-speed system communication.

2. Product Advantages & Core Features

  • 12-Slot Expansion Capacity: Dedicated slots for 1×power supply, 1×CPU, and 12×I/O/network modules for extensive system customization
  • Modular & Scalable Design: Supports multi-CPU configurations and extension rack linking to expand I/O and control capabilities as needed.
  • High-Speed Backplane Communication: Ensures fast data transfer between CPU and I/O modules, supporting high-cycle industrial applications.
  • Robust Industrial Construction: Heavy-duty metal base with secure module locking for vibration resistance in harsh environments.
  • Global Compliance: CE, UL/cUL, and UKCA certified for worldwide deployment in standard industrial control cabinetsMitsubishi Electric Europe e-shop.
  • DIN Rail Mountable: Compatible with standard DIN rails via optional adapters for easy cabinet installationMitsubishi Electric Europe e-shop.
  • Compact Footprint: Space-efficient dimensions (439×98×44.1 mm) to minimize control cabinet space usageMitsubishi Electric Europe e-shop.

3. Technical Specifications

表格



Item Specification
Model Q312B
Series MELSEC-Q Series PLC
Type Main Base Unit (Rack)
Total Slots 12 (1×Power, 1×CPU, 12×I/O)三菱电机自动化(中国)有限公司
Dimensions (W×H×D) 439 × 98 × 44.1 mmMitsubishi Electric Europe e-shop
Weight 0.45 kgMitsubishi Electric Europe e-shop
Mounting DIN rail (optional adapter) / panel mountMitsubishi Electric Europe e-shop
Operating Temperature 0°C to +55°C
Storage Temperature -25°C to +75°C
Protection Class IP20 (industrial cabinet use)
Compliance CE, UL/cUL, UKCA, RoHSMitsubishi Electric Europe e-shop
Material Heavy-duty metal base
Part Number 129566 (EU), 1W4E02 (Global)Mitsubishi Electric Europe e-shop
