Milano 220V Three Phase Inverter Milano KV90S-7D5G-4-PV 220V Three Phase Overall Dimensions：205H (mm) 105W (mm) 165D (mm) Mounting Dimensions：190A (mm) 90B (mm)
Milano 220V Three Phase Inverter Milano KV90S-7D5G-4-PV 220V Three Phase Overall Dimensions：205H (mm) 105W (mm) 165D (mm) Mounting Dimensions：190A (mm) 90B (mm)
Specifications
Packaging Details :
Pieces
Harmonic Mitigation :
Built-in or External Filters
Model Number :
KV90S-7D5G-4-PV
Certification :
CO
Operating Temperature Range :
-10°C to 50°C
Display Type :
LCD or LED Display
Power Rating :
0.5 kW to 500 kW
Output Frequency :
0-400 Hz
Cooling Method :
Forced Air Cooling
Control Method :
V/F Control, Vector Control, Sensorless Vector Control
Supply Ability :
20PCS 1week
Input Voltage :
200-480 V AC
Input Frequency :
50/60 Hz
Place of Origin :
China
Payment Terms :
T/T
Communication Protocols :
Modbus, Profibus, Ethernet/IP
Price :
Negotiable
Delivery Time :
1week
Output Voltage :
0-480 V AC
Protection Class :
IP20 to IP54
Mounting Type :
Wall-mounted or Panel-mounted
Brand Name :
Milano
Acceleration/Deceleration Time :
0.1 to 6000 seconds
MOQ :
1pcs
Overload Capacity :
150% for 1 minute
Description
Milano KV90S-7D5G-4-PV 220V Three Phase Variable Frequency Drive
Physical Dimensions
Overall Dimensions: 205H(mm) * 105W(mm) * 165D(mm)
Mounting Dimensions: 190A(mm) * 90B(mm)
Technical Specifications
Electrical Parameters by Model
Parameter -S2 (220V Single-Phase) -I (220V Single-Phase) -4 (380V Three-Phase)
Input Voltage Range (PV) 190-450V 190-450V 270-900V
Recommended Voc Voltage 300-400V 300-400V 450-700V
Optimum MPPT Voltage 310V 310V 540V
Maximum MPPT Efficiency up to 99% up to 99% up to 99%
Start-up Voltage 240V 240V 350V
Minimum Operating Voltage 190V 190V 270V
Input Voltage Range (AC) 1PH 220-240V(±10%) 1PH 220-240V(±10%) 3PH 380-480V(±10%)
Input Voltage Frequency 50/60Hz 50/60Hz 50/60Hz
Output Voltage Range 0-230V 0-230V 0-480V
Output Frequency Range 0-400Hz 0-400Hz 0-400Hz
Output Power Range 0.75-4kW 0.75-4kW 0.75-185kW
Rated Output Current by Power Rating
Power (kW) -S2 Current (A) -I Current (A) -4 Current (A)
0.75952.7
1.51373.7
2.218105
323137
428179
5.5402513
7.5603217
11754525
15906032
18.51107537
221509045
3017611060
3721015075
45176110
55210150
75176
90210
110250
132300
160340
185400
Performance Characteristics
Motor Compatibility: Single phase motor, Asynchronous motors, Permanent magnet synchronous motor
Control Modes: V/F control, Open-Loop Vector Control, Closed-Loop Vector Control
Overload Capacity: 150% rated load for 60s; 180% for 10s; 200% for 0.5s
Installation: Wall-mounted
Protection Class: IP20
Working Temperature: -10°C to +50°C (derating 2% per °C above 40°C)
Cooling Method: Forced air cooling
Humidity: 20%-95%RH (condensation free)
Installation Altitude: Up to 1000m (derating 1% per 100m above)
