Siemens 6GK5004-1GL10-1AB2 SCALANCE XB004-1 G Unmanaged IE Switch 4x RJ45 + 1x SC (Multimode Fiber)
Siemens 6GK5004-1GL10-1AB2 SCALANCE XB004-1 G Unmanaged IE Switch 4x RJ45 + 1x SC (Multimode Fiber)
Specifications
Brand Name :
Siemens
Model Number :
6GK5004-1GL10-1AB2
Place of Origin :
Germany
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20PCS 1WEEK
Delivery Time :
1WEEK
Port Speed :
10/100/1000 Mbps
Operating Temperature Range :
-40°C to 85°C
Certifications :
CE, FCC, UL, RoHS
Led Indicators :
Power, link/activity, speed
Ingress Protection Rating :
IP30 to IP67
Enclosure Material :
Aluminum or steel
Redundancy Support :
Yes, power and network redundancy
Management Interface :
Web GUI, CLI, SNMP
Weight :
0.5 to 2 kg
Power Supply :
12-48V DC
Network Protocols Supported :
TCP/IP, UDP, SNMP, Modbus TCP
Mounting Type :
DIN rail or panel mount
Ethernet Ports :
8 to 24 ports
Dimensions :
Varies by model, typically 150x100x50 mm
Description
Siemens SCALANCE XB004-1 G Unmanaged Industrial Ethernet Switch
The Siemens 6GK5004-1GL10-1AB2 SCALANCE XB004-1 G is an unmanaged industrial Ethernet switch featuring 4x RJ45 ports and 1x SC multimode fiber port with Gigabit transmission capability, designed for reliable network connectivity in industrial environments.
Product Specifications
Product Series SCALANCE XB004-1 G
Part Number 6GK5004-1GL10-1AB2
Model Name XB004-1 G
Switch Type Unmanaged Industrial Ethernet Switch
Port Configuration 4x RJ45 + 1x SC (Multimode Fiber)
Transmission Rate 10/100/1000 Mbit/s (Gigabit)
Power Supply 24V DC (19.2~28.8V DC)
Rated Power Loss 2.5W
Dimensions (WxHxD) 45mm x 100mm x 87mm
Net Weight 0.155kg
Protection Class IP20
Mounting Type 35mm DIN Rail/Wall Mount
Operating Temperature -10°C to +60°C
Key Features
  • Gigabit transmission capability for high-speed data transfer
  • Multimode fiber extension with maximum 750m fiber distance
  • LED diagnostics for easy network monitoring and troubleshooting
  • Plug & Play operation for simple installation
  • Industrial-grade construction for harsh environments
  • Compact design suitable for space-constrained installations
SCALANCE XB004 Series Comparison
Model Port Configuration Transmission Rate Fiber Type Max Fiber Distance Key Features
XB004 SMART 4x RJ45 10/100 Mbit/s Twisted Pair - LED Diagnostics; Plug & Play; Small Star/Line Topology
XB004-1 4x RJ45 + 1x SC 10/100 Mbit/s Multimode 2km LED Diagnostics; Fiber Extension
XB004-1 LD 4x RJ45 + 1x SC 10/100 Mbit/s Singlemode 10km LED Diagnostics; Long Distance Fiber
XB004-1 G 4x RJ45 + 1x SC 10/100/1000 Mbit/s Multimode 750m Gigabit Transmission; LED Diagnostics
XB004-1 LDG 4x RJ45 + 1x SC 10/100/1000 Mbit/s Singlemode 10km Gigabit Fiber; Plug & Play
XB004-2 4x RJ45 + 2x SC 10/100 Mbit/s Multimode 2km each Dual Fiber Ports; 1024 MAC Addresses
XB004-2 LD 4x RJ45 + 2x SC 10/100 Mbit/s Singlemode 10km each Dual Long-Distance Fiber; LED Diagnostics
